Price:
NZ$ 291.05 including GST
NZ$ 253.09 excluding GST
or four payments of $72.76
with
Learn More
each
A5580S
1
Information
AH2035MAssociated Numbers
Atlantic Quality Parts 1700-0518 Lester 12132 Mitsubishi A1T22074 AH2035M AH2035M4 MD017645 PIC Picture ID 203-102 203-125 Remy Light Duty 50925 Wilson 90-27-3081 J N 400-48100 References: J& J&N 0210006980 Denso 027645 Andre Niermann 030983 Da Silva 1000197467 Weidemann 10441660 Alanko 111042 HC-Cargo 12060487 EuroTec 12132N WAI 14314105 Dixie 155009035 PSH 203102 2040133 Sando 2325 CEVAM 271618 Elstock 40872 DAS 436504 Valeo 441006 Logistik 441660 526002352 DRI 5527656812 Schaeff 561008 566301764500 Iseki 664411B Other 7410059 Volvo 75899 EAI 89212872 PowerMax 8EL732718001 Hella 933443 EDR A001T11574 A001T22074 A130493 Short code A158157 A161566 A1T11574 A8391 ACA322 ATK AGN80872 ADI AGN80872D AH2025M4 AH2035MSEL +line AH2035MY AL00183 TMI ALT31167 Wood Auto AME1008 Everkraft AMI1134 Quasar CAL40133 Casco CAL40133AS CGB71618 Ainde DRA3443 Delco IR6590 Protech JA872 HC-Parts JA872IR LRA01091 Lucas LRA1091 MD017623 MD017635 MD017646 RNLA1T11574 RNL SP5446 Spidan TRA318 TWA WOOALT31167 International Harvester 1273116C91 Truck 90-27-3081NSpecifications
| Amp | 35 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 8.5 mm |
| Length (L.1) | 162 mm |
| Mount Inside Length or Pad Mount C-C (C) | 65.5 mm |
| Plug Code | PL_9007 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 39 mm |
| Pulley Outside Diameter (O.D.2) | 62 mm |
| Pulley to Mount Distance (A) | 41 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | 234 | 01.1985-12.1986 | |
| CASE | 235 | 01.1986-12.1990 | |
| CASE | 244 | 01.1985-12.1986 | |
| CASE | 245 | 01.1986-12.1990 | |
| CASE | 254 | 01.1985-12.1986 | |
| CASE | 255 | 01.1986-12.1990 | |
| CASE | 265 | 01.1987-12.1991 | |
| CASE | 275 | 01.1986-12.1991 | |
| GROUNDSMASTER | 322D | 01.1981-12.1990 | |
| GROUNDSMASTER | 325D | 01.1991-12.2001 | |
| INTERNATIONAL | 234 | 01.1982-12.1984 | |
| INTERNATIONAL | 244 | 01.1982-12.1984 | |
| INTERNATIONAL | 254 | 01.1982-12.1985 | |
| TORO | 325D | ||
| WHITE | 16 4WD Field Boss | 01.1987-12.1989 | |
| WHITE | 16 Field Boss | 01.1987-12.1989 |
Reference Information
90-27-3081 AL00183 JA872IR 155.009.035.460 20040133AV AH2035MY 10441660 441006 526002352 JA872 ANM35663 MD017635 AH2035M 3112202 IR6590 DRA3443 UD102567A 2325 2040133.0 G103493 119148 3112200 20132331BN 111042 27-1618CT WOOALT31167 155.009.035.130 F032111042 12060487 40872 75899 A1T22074 AZMT-49-035-2083 ALT31167 12132N MD017645 CAL40133AS 899ST57 LRA01091 AH2035M4 27-1618 PL8326 A001T22074 ALM0385 LRA191 A12MH0359A2View your shopping basket or Browse other items in Alternators.
