Price:
NZ$ 615.37 including GST
NZ$ 535.10 excluding GST
or four payments of $153.84
with
Learn More
each
A9536S
No stock in NZ
No stock in NZ
Specifications
| Amp | 175 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 13 mm |
| Diameter (D.2) | UNC 1/2"-13G mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 235 mm |
| Mount Inside Length or Pad Mount C-C (C) | 103 mm |
| Plug Code | PL_9105 |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 62 mm |
| Pulley to Mount Distance (A) | 31 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Steiger 330 | [6-540] | 01.2006-12.2007 |
| CASE | Steiger 335 9.0 | [6-543] | 01.2008-12.2012 |
| CASE | Steiger 380 12.9 | [6-787] | 01.2006-12.2007 |
| CASE | Steiger 385 12.9 | [6-787] | 01.2008-12.2012 |
| CASE | Steiger 430 12.9 | [6-787] | 01.2006-12.2007 |
| CASE | Steiger 435 12.9 | [6-787] | 01.2008-12.2012 |
| CASE | Steiger 480 14.9 | [6-912] | 01.2007-12.2008 |
| CASE | Steiger 480 14.9 | [QSX15] | 01.2007-12.2008 |
| CASE | Steiger 485 12.9 | [6-787] | 01.2008-12.2012 |
| CASE | Steiger 530 14.9 | [6-912] | 01.2007-12.2008 |
| CASE | Steiger 530 14.9 | [QSX15] | 01.2007-12.2008 |
| CASE | Steiger 535 15.0 | [6-915] | 01.2008-12.2012 |
| CASE | Steiger 535 15.0 | [QSX15] | 01.2008-12.2012 |
| CASE | STX280 | [6-505] | 01.2006-12.2007 |
| CASE | STX330 | [6-540] | 01.2006-12.2007 |
| CASE | STX380 | [6-786] | 01.2006-12.2007 |
| CASE | STX430 | [6-786] | 01.2006-12.2007 |
| CASE | STX480 | [6-912] | 01.2006-12.2007 |
| CASE | STX480 | [QSX15] | 01.2006-12.2007 |
| CASE | STX530 | [6-912] | 01.2006-12.2007 |
| CASE | STX530 | [QSX15] | 01.2006-12.2007 |
| CASE | WD1203 4.5 | [4-274] | 01.2007-12.2013 |
| CASE | WD1903 6.7 | [6-411] | 01.2007-12.2013 |
| CASE | WD2303 6.7 | [6-411] | 01.2007-12.2013 |
| NEW HOLLAND | H8040 4.5 | [4-274] | 01.2007-12.2013 |
| NEW HOLLAND | H8060 6.7 | [6-411] | 01.2007-12.2013 |
| NEW HOLLAND | H8080 6.7 | [6-411] | 01.2007-12.2013 |
| NEW HOLLAND | T9010 8.3 | 01.2007-12.2011 | |
| NEW HOLLAND | T9020 9.0 | 01.2007-12.2011 | |
| NEW HOLLAND | T9030 12.9 | 01.2006-12.2012 | |
| NEW HOLLAND | T9040 12.9 | 01.2006-12.2012 | |
| NEW HOLLAND | T9050 12.9 | 01.2006-12.2012 | |
| NEW HOLLAND | T9060 15.0 | [QSX] | 01.2006-12.2012 |
| NEW HOLLAND | TJ280 8.3 | 01.2006-12.2007 | |
| NEW HOLLAND | TJ330 9.0 | 01.2006-12.2007 | |
| NEW HOLLAND | TJ380 9.0 | 01.2006-12.2007 | |
| NEW HOLLAND | TJ430 12.9 | 01.2006-12.2007 | |
| NEW HOLLAND | TJ480 15.0 | [QSX] | 01.2006-12.2007 |
| NEW HOLLAND | TJ530 15.0 | [QSX] | 01.2006-12.2007 |
Reference Information
AAN5185 655.502.175.090 282-30115NOE MG685 11.203.742 72735266 20119172OE MAHMG267 CAL21271AS G104520 ALI8153 05042937750 115243 87720193 87720193R 87439317 87439313 6220229M91 ALTE281 UD102790A LEA1298 DRA1333 20119172BN AAN5714 AAN8153 TT13010 MG267 504132109 CAL21271GS WG2043542 11.203.322 2569 ALTE273 WOOALT20695 89215890 11.204.241 87677208 87677207 ALT20695 IA1159 ALT232710A 90-23-6576 282-30115 ALT79434 2021271.0 G105189 504293775 2021271.1 655.502.175.311 655.502.175.310View your shopping basket or Browse other items in Alternators.
