Price:
NZ$ 519.44 including GST
NZ$ 451.69 excluding GST
or four payments of $129.86
with
Learn More
each
A9534S
No stock in NZ
No stock in NZ
Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Length (L.1) | 167 mm |
| Mount Inside Length or Pad Mount C-C (C) | 50 mm |
| Plug Code | PL_3307 |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 58 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | CLUTCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Celesta | 01.2016- | |
| HYUNDAI | Creta | 01.2016-12.2020 | |
| HYUNDAI | G70 | 01.2018-12.2020 | |
| HYUNDAI | G80 | 01.2017-12.2019 | |
| HYUNDAI | G90 | 01.2016-12.2019 | |
| HYUNDAI | G90 | 01.2019- | |
| HYUNDAI | Grand I10 | 01.2017-12.2020 | |
| HYUNDAI | ix25 | 01.2017-12.2019 | |
| HYUNDAI | ix35 | 01.2017-12.2020 | |
| HYUNDAI | Kona | 01.2019- | |
| HYUNDAI | Lafesta | 01.2018- | |
| HYUNDAI | Mistra | 01.2016-12.2020 | |
| HYUNDAI | Sonata | 01.2019- | |
| HYUNDAI | Verna | 01.2016-12.2019 | |
| HYUNDAI | Verna | 01.2019- | |
| KIA | Forte | 01.2017-12.2021 | |
| KIA | K2 | 01.2016-12.2020 | |
| KIA | Picanto | 01.2017-12.2020 | |
| KIA | Telluride | 01.2019-12.2022 |
Reference Information
UD102171A 37300-2B410 8400388 11202View your shopping basket or Browse other items in Alternators.
