Price:
NZ$ 319.80 including GST
NZ$ 278.09 excluding GST
or four payments of $79.95
with
Learn More
each
A6861S
No stock in NZ
No stock in NZ
Specifications
| Amp | 30 A |
| Bottom Mounting Foot Width (B) | 24 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 162 mm |
| Plug Code | PL_2500 |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10 mm |
| Pulley Outside Diameter (O.D.1) | 43 mm |
| Pulley Outside Diameter (O.D.2) | 69 mm |
| Pulley to Mount Distance (A) | 45 mm |
| Pulley Type | SOLID |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CASE | Maxi-Sneaker | [V1505-B] | 01.1993-12.2001 |
| GEHL | SL3825 | [V1305E] | 01.1991-12.2001 |
| HUSQVARNA | HUV4420D | [D722] | 01.2005-12.2011 |
| HUSQVARNA | HUV4420DXP | [D722] | 01.2005-12.2011 |
| HUSQVARNA | HUV4421D | [D722] | 01.2009-12.2011 |
| HUSQVARNA | HUV4421DXL | [D722] | 01.2009-12.2011 |
| HUSQVARNA | HUV4421DXP | [D722] | 01.2009-12.2011 |
| KUBOTA | KX121-2 | [V2203BH] | 01.1996-12.2002 |
| KUBOTA | KX121-2S | [V2203EBH] | 01.2000-12.2010 |
| KUBOTA | KX161-2 | [V2203BH] | 01.1995-12.2005 |
| KUBOTA | KX161-2S | [V2203EBH] | 01.2000-12.2010 |
| KUBOTA | L2650F | [D1402DIAE] | 01.1991-12.1993 |
| KUBOTA | L2650GST | [D1402DIAE] | 01.1991-12.1993 |
| KUBOTA | L2900DT | [D1503LA] | 01.1994-12.1998 |
| KUBOTA | L2900DTGST | [D1503LA] | 01.1994-12.1998 |
| KUBOTA | L2900F | [D1503LA] | 01.1994-12.1998 |
| KUBOTA | L2900GST | [D1503LA] | 01.1994-12.1998 |
| KUBOTA | L2950F | [D1462DIAE] | 01.1991-12.1993 |
| KUBOTA | L2950GST | [D1462DIAE] | 01.1991-12.1993 |
| KUBOTA | L3010DT | [D1503LAN] | 01.1998-12.2002 |
| KUBOTA | L3010F | [D1503LAN] | 01.1998-12.2002 |
| KUBOTA | L3010GST | [D1503LAN] | 01.1998-12.2002 |
| KUBOTA | L3010HST | [D1503LAN] | 01.1998-12.2002 |
| KUBOTA | L3300DT | [D1703A] | 01.1994-12.1998 |
| KUBOTA | L3300DTGST | [D1703A] | 01.1994-12.1998 |
| KUBOTA | L3300F | [D1703A] | 01.1994-12.1998 |
| KUBOTA | L3300GST | [D1703A] | 01.1994-12.1998 |
| KUBOTA | L3410DT | [D1703A] | 01.1998-12.2002 |
| KUBOTA | L3410GST | [D1703A] | 01.1998-12.2002 |
| KUBOTA | L3410HST | [D1703A] | 01.1998-12.2002 |
| KUBOTA | L35TL | [D1703TLB] | 01.1999-12.2004 |
| KUBOTA | L35TLB | [D1703TLB] | 01.1999-12.2004 |
| KUBOTA | L3600DT | [V1903A] | 01.1994-12.1998 |
| KUBOTA | L3710GST | [V1903AN] | 01.1998-12.2002 |
| KUBOTA | L3710HST | [V1903AN] | 01.1998-12.2002 |
| KUBOTA | L4200DT | [V2203A] | 01.1994-12.1998 |
| KUBOTA | L4200GSTCA | [V2203A] | 01.1994-12.1998 |
| KUBOTA | L4310DT | [V2203AN] | 01.1998-12.2002 |
| KUBOTA | L4310F | [V2203AN] | 01.1998-12.2002 |
| KUBOTA | L4310GST | [V2203AN] | 01.1998-12.2002 |
| KUBOTA | L4310HST | [V2203AN] | 01.1998-12.2002 |
| KUBOTA | L4610GST | [V2203EHA] | 01.1999-12.2002 |
| KUBOTA | L4610HST | [V2203EHA] | 01.1999-12.2002 |
| KUBOTA | L48TL | [V2403] | 01.2000-12.2009 |
| KUBOTA | L48TLB | [V2403] | 01.2000-12.2009 |
| KUBOTA | M4700DT | [F2803ELA] | 01.1995-12.1997 |
| KUBOTA | M4700F | [F2803ELA] | 01.1995-12.1997 |
| RED-D-ARC | D300K | 01.1997-12.2007 | |
| THOMAS | 175 | [V2203T] | |
| THOMAS | T153 | [V2203E] | 01.2000-12.2002 |
| THOMAS | T153S | [V2203E] | 01.2000-12.2002 |
| THOMAS | T84 | [D722B] | 01.1989-12.1998 |
| TORO | Groundsmaster 228D | [28H.P.] | 01.2001-12.2004 |
| TORO | Groundsmaster 3280-D | [28H.P.] | 01.2005-12.2009 |
| TORO | Groundsmaster 328D | [28H.P.] | 01.2001-12.2009 |
| TORO | Groundsmaster 3500-D | [35H.P.] | 01.2000-12.2009 |
| TORO | Groundsmaster 7200 | [28H.P.] | 01.2007-12.2009 |
| TORO | Groundsmaster 7210 | [35H.P.] | 01.2007-12.2009 |
| TORO | Reelmaster 3100-D | [21.5H.P.] | 01.1999-12.2009 |
| TORO | Reelmaster 5200-D | [28H.P.] | 01.1998-12.2006 |
| TORO | Reelmaster 5210 | [28H.P.] | 01.2006-12.2009 |
| TORO | Reelmaster 5400-D | [35.5H.P.] | 01.1998-12.2006 |
| TORO | Reelmaster 5410 | [35.5H.P.] | 01.2006-12.2009 |
| TORO | Reelmaster 5500-D | [35.5H.P.] | 01.2000-12.2006 |
| TORO | Reelmaster 5510 | [35.5H.P.] | 01.2006-12.2009 |
| TORO | Reelmaster 5610 | [44.2H.P.] | 01.2006-12.2009 |
| TORO | Reelmaster 6500-D | [46H.P.] | 01.1997-12.2009 |
| TORO | Reelmaster 6700-D | [46H.P.] | 01.2000-12.2009 |
| TORO | Z580-D Z Master | [23H.P.] | 01.2008-12.2009 |
| TORO | Z580-D Z Master | [25H.P.] | 01.2008-12.2009 |
| TORO | Z593-D Z Master | [23H.P.] | 01.2006-12.2007 |
| TORO | Z595-D Z Master | [25H.P.] | 01.2007-12.2007 |
Reference Information
447070 AL03551 12206N LRA4000 G103718 ADN567 LEA0470 ALN4640 554472RI ANM98723 16427-64013 ALT30004 985.510.030.050 LRA04000 021080-0780 G101373 DAN2020 CAL40567GS ALT425670 IR6708 3127785 WG1916867 F032113921 113921 20132765OE UD103185A 985.510.030.260 100211-4610 100211-4611 STX101078R 100211-4612 10441487 290-10251 20040567OV 2040567.1 583118402 BREF032113921 111193 28-7610View your shopping basket or Browse other items in Alternators.
