Price:
NZ$ 1,156.72 including GST
NZ$ 1,005.84 excluding GST
or four payments of $289.18
with
Learn More
each
A0802(SEG)
No stock in NZ
No stock in NZ
Specifications
| Amp | 120 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | 13 mm |
| Length (L.1) | 210 mm |
| Mount Inside Length or Pad Mount C-C (C) | 108 mm |
| Pad mount thickness (E.1) | 80 mm |
| Pad mount thickness (E.2) | 80 mm |
| Plug Code | PL_5003 |
| Pulley Grooves | 8 qty |
| Pulley Outside Diameter (O.D.1) | 73 mm |
| Pulley to Mount Distance (A) | 36 mm |
| Pulley Type | SOLID |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DAF | CF FA 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FA 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FA 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAC 410 12.9 | [MX-13303] | 12.2015- |
| DAF | CF FAC 460 12.9 | [MX-13340] | 12.2015- |
| DAF | CF FAC 510 12.9 | [MX-13375] | 12.2015- |
| DAF | CF FAD 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAD 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAD 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAG 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAG 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAG 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAN 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAN 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAN 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAQ 410 12.9 | [MX-13303] | 12.2015- |
| DAF | CF FAQ 460 12.9 | [MX-13340] | 12.2015- |
| DAF | CF FAQ 510 12.9 | [MX-13375] | 12.2015- |
| DAF | CF FAR 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAR 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAR 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAS 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAS 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAS 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAT 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FAT 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FAT 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FAX 410 12.9 | [MX-13303] | 12.2015- |
| DAF | CF FAX 460 12.9 | [MX-13340] | 12.2015- |
| DAF | CF FAX 510 12.9 | [MX-13375] | 12.2015- |
| DAF | CF FT 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FT 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FT 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FTG 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FTG 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FTG 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FTP 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FTP 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FTP 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FTR 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FTR 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FTR 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FTS 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FTS 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FTS 510 12.9 | [MX-13375] | 05.2013- |
| DAF | CF FTT 410 12.9 | [MX-13303] | 05.2013- |
| DAF | CF FTT 460 12.9 | [MX-13340] | 05.2013- |
| DAF | CF FTT 510 12.9 | [MX-13375] | 05.2013- |
| DAF | XF FA 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FA 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FA 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FAD 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FAD 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FAK 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FAK 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FAK 510 12.9 | [MX-13375] | 12.2012- |
| DAF | XF FAN 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FAN 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FAN 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FAR 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FAR 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FAR 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FAS 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FAS 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FAS 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FAT 460 12.9 | [MX-13340] | 06.2015- |
| DAF | XF FAT 510 12.9 | [MX-13375] | 06.2015- |
| DAF | XF FT 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FT 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FT 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTG 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FTG 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTG 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTM 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTM 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTN 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FTN 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTN 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTP 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FTP 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTP 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTR 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FTR 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTR 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTS 410 12.9 | [MX-13303] | 10.2012- |
| DAF | XF FTS 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTS 510 12.9 | [MX-13375] | 10.2012- |
| DAF | XF FTT 460 12.9 | [MX-13340] | 10.2012- |
| DAF | XF FTT 510 12.9 | [MX-13375] | 10.2012- |
Reference Information
A148P385 554884RIB WG2203041 0986085640 21656N AL04605 444411 906.512.120.010 1986A01024 8EL012584-951 906.512.120.210 A24BH0101A2 906.512.120.212 1976290 CAL10751GS 3127178 1927310R ALB2862 1927310 WG2283024 72496013 0124655407 0124655408 202023 443479 ABO751 LEA0969 0124655296 0124655295 G100832 A24BH0101 IA9490 114800 48-8723 ALT79848 DA2735 LRA4614 442656 ALT1651 1872181 0124655386 11.209.461 5610082G 0124655385 DRA1625 MG936 UD04920(SEG)A 5461011204 H5610082G 2000904 AAN8206 183198 20101157OE 2614 2010751.1 20010751OV 1976290R 0124655111 LRA04614 906.512.120.280 G101107 1886885View your shopping basket or Browse other items in Alternators.
