Price:
NZ$ 575.17 including GST
NZ$ 500.15 excluding GST
or four payments of $143.79
with
Learn More
each
A01039S
No stock in NZ
No stock in NZ
Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 59 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 215 mm |
| Plug Code | PL_3314 |
| Pulley Grooves | 10 qty |
| Pulley Outside Diameter (O.D.1) | 62 mm |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| IVECO | 180 E 24 W 7.8 Cursor | [F2BE0681D] | 09.1999-11.2004 |
| IVECO | 190 E 24 7.8 | [F2BE0681D] | 09.1998- |
| IVECO | 190 E 24 H 7.8 Cursor | [F2BE0681D] | 09.1999-11.2004 |
| IVECO | 190 E 24 K 7.8 | [F2BE0681D] | 09.1998- |
| IVECO | 190 E 24 P 7.8 | [F2BE0681D] | 09.1998- |
| IVECO | 190 E 27 7.8 | [F2BE0681C] | 09.1998- |
| IVECO | 190 E 27 7.8 | [F2BE0681C] | 10.2000-11.2004 |
| IVECO | 190 E 27 7.8 | [F2BE0681F] | 09.1998- |
| IVECO | 190 E 27 7.8 | [F2BE0681F] | 10.2000-11.2004 |
| IVECO | 190 E 27 K 7.8 | [F2BE0681C] | 09.1998- |
| IVECO | 190 E 27 K 7.8 | [F2BE0681F] | 09.1998- |
| IVECO | 190 E 27 P 7.8 | [F2BE0681C] | 09.1998- |
| IVECO | 190 E 27 P 7.8 | [F2BE0681F] | 09.1998- |
| IVECO | 190 E 31 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 190 E 31 H 7.8 Cursor | [F2BE0681B] | 09.1999-11.2004 |
| IVECO | 190 E 31 K 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 190 E 31 P 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 190 E 31 W 7.8 Cursor | [F2BE0681B] | 09.1999-11.2004 |
| IVECO | 190 E 35 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 190 E 35 FP 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 190 E 35 H 7.8 Cursor | [F2BE0681A] | 09.1999-11.2004 |
| IVECO | 190 E 35 P 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 190 E 35 W 7.8 Cursor | [F2BE0681A] | 09.1999-11.2004 |
| IVECO | 190S27 7.8 | [F2BE0681C] | 06.2003- |
| IVECO | 190S27 7.8 | [F2BE0681F] | 04.2004- |
| IVECO | 190S27 7.8 | [F2BE0681F] | 06.2003- |
| IVECO | 190S27P 7.8 CNG | [F2BFA601G] | 09.2012- |
| IVECO | 190S30 7.8 | [F2BE0681E] | 04.2004- |
| IVECO | 190S30P 7.8 CNG | [F2BFA601K] | 09.2012- |
| IVECO | 190S31 7.8 | [F2BE3681C] | 04.2004- |
| IVECO | 190S31 8.7 | [F2CFE611D] | 09.2012- |
| IVECO | 190S31FP 8.7 | [F2CFE611D] | 09.2012- |
| IVECO | 190S33 7.8 | [F2BE3681B] | 05.2007- |
| IVECO | 190S35 7.8 | [F2BE0681A] | 04.2004- |
| IVECO | 190S36 7.8 | [F2BE3681A] | 05.2007- |
| IVECO | 190S45 10.3 | [F3AE3681A] | 12.2006- |
| IVECO | 260 E 24 Y/P 7.8 | [F2BE0681D] | 11.1999- |
| IVECO | 260 E 24 Y/PS 7.8 | [F2BE0681D] | 11.1999- |
| IVECO | 260 E 24 Y/PT 7.8 | [F2BE0681D] | 11.1999- |
| IVECO | 260 E 27 RY/PS 7.8 | [F2BE0681C] | 11.1999- |
| IVECO | 260 E 27 RY/PS 7.8 | [F2BE0681F] | 11.1999- |
| IVECO | 260 E 27 RY/PT 7.8 | [F2BE0681C] | 11.1999- |
| IVECO | 260 E 27 RY/PT 7.8 | [F2BE0681F] | 11.1999- |
| IVECO | 260 E 27 Y/P 7.8 | [F2BE0681C] | 11.1999- |
| IVECO | 260 E 27 Y/P 7.8 | [F2BE0681F] | 11.1999- |
| IVECO | 260 E 27 Y/PS 7.8 | [F2BE0681C] | 11.1999- |
| IVECO | 260 E 27 Y/PS 7.8 | [F2BE0681F] | 11.1999- |
| IVECO | 260 E 31 H 7.8 Cursor | [F2BE0681B] | 09.1999-11.2004 |
| IVECO | 260 E 31 HB 7.8 Cursor | [F2BE0681B] | 11.1999-11.2004 |
| IVECO | 260 E 31 Y/P 7.8 | [F2BE0681B] | 11.1999- |
| IVECO | 260 E 31 Y/PS 7.8 | [F2BE0681B] | 11.1999- |
| IVECO | 260 E 31 Y/PT 7.8 | [F2BE0681B] | 11.1999- |
| IVECO | 260 E 35 H 7.8 Cursor | [F2BE0681A] | 01.2000-11.2004 |
| IVECO | 260 E 35 W 7.8 Cursor | [F2BE0681A] | 09.1999-11.2004 |
| IVECO | 260 E 35 Y/P 7.8 | [F2BE0681A] | 11.1999- |
| IVECO | 260 E 35 Y/PT 7.8 | [F2BE0681A] | 11.1999- |
| IVECO | 260 E 35 Y/TN 7.8 | [F2BE0681A] | 11.1999- |
| IVECO | 260S27 7.8 | [F2BE0681F] | 04.2004- |
| IVECO | 260S27 7.8 CNG | [F2BE0641] | 01.2008- |
| IVECO | 260S30 7.8 | [F2BE0681E] | 04.2004- |
| IVECO | 260S30 7.8 | [F2BE0681E] | 10.2005- |
| IVECO | 260S31 7.8 | [F2BE0681B] | 06.2003- |
| IVECO | 260S31 7.8 | [F2BE3681C] | 04.2004- |
| IVECO | 260S31 7.8 | [F2BE3681C] | 06.2003- |
| IVECO | 260S33 7.8 | [F2BE3681B] | 06.2007- |
| IVECO | 260S33 7.8 | [F2BE3681B] | 12.2006- |
| IVECO | 260S35 7.8 | [F2BE0681A] | 06.2003- |
| IVECO | 260S35 7.8 | [F2BE3681A] | 06.2003- |
| IVECO | 260S36 7.8 | [F2BE0681A] | 06.2003- |
| IVECO | 260S36 7.8 | [F2BE3681A] | 06.2003- |
| IVECO | 260S36 7.8 | [F2BE3681A] | 07.2007- |
| IVECO | 261 E 31 Y/P 7.8 | [F2BE0681B] | 11.1999- |
| IVECO | 340 E 35 H 7.8 Cursor | [F2BE0681A] | 09.1999-11.2004 |
| IVECO | 380 E 35 H 7.8 Cursor | [F2BE0681A] | 01.2000-11.2004 |
| IVECO | 380 E 35 W 7.8 Cursor | [F2BE0681A] | 01.2000-11.2004 |
| IVECO | 400 E 31 TP 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 400 E 35 HT 7.8 Cursor | [F2BE0681A] | 01.2000-11.2004 |
| IVECO | 400 E 35 TP 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 410 E 35 H 7.8 Cursor | [F2BE0681A] | 01.2000-11.2004 |
| IVECO | 440 E 31 T 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 440 E 31 TP 7.8 | [F2BE0681B] | 09.1998- |
| IVECO | 440 E 35 T 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 440 E 35 T/FP 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 440 E 35 T/P 7.8 | [F2BE0681A] | 09.1998- |
| IVECO | 440 E 35 TX/P 7.8 | [F2BE0681A] | 02.2000- |
| IVECO | 440S31 7.8 | [F2BE0681B] | 06.2003- |
| IVECO | 440S33 7.8 | [F2BE3681B] | 12.2006- |
| IVECO | 440S35 7.8 | [F2BE0681A] | 06.2003- |
| IVECO | 440S35 7.8 | [F2BE3681A] | 06.2003- |
| IVECO | 440S36 7.8 | [F2BE0681A] | 06.2003- |
| IVECO | 440S36 7.8 | [F2BE3681A] | 06.2003- |
Reference Information
CAL10604GS G102826 20923N CAL10604AS 0123525508 G106148 506.502.090.130 20101406BN 302040RIM ALT1359 506.502.090.010 506.502.090.390 506.502.090.370 302040RI UD103322A 99477271 ALT126300 ALT126040 20101406OE 2010604.2 G103338 2010604.1 2010604.0 504065776 A4TA8491 BREF0320986045170 ALB1633 WG2280792 500331736 A004TA8491 5801315646 506.502.090.210 ALT126040A 113923 175825 0986045170 CA2040IR F032113923 CAL10604RS 20101406RC T002002050 G100334 BREF032113923 504286394View your shopping basket or Browse other items in Alternators.
