Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 406.70 including GST
NZ$ 353.65 excluding GST
or four payments of $101.68
with
Learn More
each
A6813S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 55 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Length (L.1) | 177 mm |
| OEM Product | No |
| Plug Code | PL_3302 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 2 qty |
| Pulley Groove Width (W.1) | 12.5 mm |
| Pulley Outside Diameter (O.D.1) | 51 mm |
| Pulley Outside Diameter (O.D.2) | 79 mm |
| Pulley to Mount Distance (A) | 93 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| YANMAR | Engine | [6LPA-DTEP] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-DTZEP1] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-STEP] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-STZEP] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-STZEP1] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-STZP2] | 01.1997-12.2007 |
| YANMAR | Engine | [6LPA-STZP3] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-DT] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-DTE] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-DTZE1] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-DTZY] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-ST] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-STE] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-STZE] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-STZE1] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-STZY] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-STZYJ] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-WDT] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-WDTZY] | 01.1997-12.2007 |
| YANMAR | Engine | [6LP-WST] | 01.1997-12.2007 |
Reference Information
70-29-12355 CCB-13078 LRA2144 12355N 447153 ALT30185 553947RI 113715 27060-73020 ALT0100 F032113715 A12DE1124A2 3127770 28-4591 3127771 ADN142A 89214003 CAL40142AS 582116802 119773-77200 985.501.075.050 20132241BN 20040142AV LRA02144 AL02216 LEA0248 L611462 290-10197 UD30178A 2040142.0 2718 WOOALT30185Video/Publications
A6813SRelated Items
