Specifications
| Kilowatt | 1.1 kW |
| Length (L.1) | 186 mm |
| Mount Hole Center - Center (O.1) | 127 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 13 qty |
| OEM Product | No |
| Pinion at Rest (B) | 23 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 64 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Argo 1.0 | 01.2016- | |
| FIAT | Argo 1.3 | 01.2016- | |
| FIAT | Cronos 1.3 | 01.2016- | |
| FIAT | Mobi 1.0 | 01.2016- | |
| FIAT | Mobi 1.3 | 01.2016- | |
| FIAT | Uno 1.0 | 01.2016- | |
| FIAT | Uno 1.3 | 01.2016- |
Reference Information
500.596.132.280 0001194019 52033810 500.596.132.018 UD19703S S0899S 52033809 STB2505 0001194020Video/Publications
