Associated Numbers
04557301
0986080630 Bosch ruil
0986CN0256 Bosch ruil
0986CN0258 Bosch ruil
0986CR0256 Bosch ruil
0986CR0260 Bosch ruil
0986UR0256 Bosch ruil
0986UR0260 Bosch ruil
111193 Cargo
113055 Cargo
113063 Cargo
12090038 EuroTec
12090073 EuroTec
1210003000 Denso show
1210003310 Denso show
121000333 Denso
1210003330 Denso show
1210003370 Denso show
121000338 Denso
1210003380 Denso show
1210003380SEL +line
1210003390 Denso show
1210003400 Denso show
1210003450 Denso show
1210003452 Denso show
1210003470 Denso show
1210003471 Denso
121000353 Denso
1210003530 Denso show
1210003531 Denso show
1210003600 Denso show
13245 Lester
13354 Lester
272569 Elstock
272571 Elstock
273600 Elstock
273603 Elstock
273716 Elstock
290269 PIC
437751 Valeo
500045902 DRI
5234027 Chrysler
5234028 Chrysler
5234029 Chrysler
5234032 Chrysler
53008647
534020902 DRI
5532SP Spidan
56005684 Chrysler
56005685 Chrysler
56005685AB Chrysler
56027912 Chrysler
835510090 PSH
90295110 Wilson
90295115 Wilson
90295122 Wilson
90295131 Wilson
9090081 Friesen
9090081F Friesen
933788 EDR
9712109338 Denso
AL581X Bosch (USA)
AL6505X Bosch (USA)
AL6506N Bosch (USA)
AL6506X Bosch (USA)
AL6509N Bosch (USA)
AL6509X Bosch (USA)
AL6511X Bosch (USA)
ALT5046 Unipoint
ALT5066 Unipoint
ALT6084sa Electrolog
DRA3788 Remy
DRZ0185 Remy
F042302031 Bosch
F042302057 Bosch
HUA960IR HC
L69450 ATL
LRA01132 Lucas
LRA01139 Lucas
LRB00239 Lucas
UA960 HC
UA960IR HC
Substitutes:
Wilson 90-29-5122
References:
Bosch AL585X, AL6509N, AL6509X, AL6513X, AL6518X
Chrysler 56005685, 56005685AB, 59005685
Denso 121000-3450, 121000-3451, 121000-3452, 210-0130, 9712109-345
Lester 13341
PIC Picture ID 290-301
Wilson 90-29-5122
J&N 400-52039
Denso 9712109-345
References:
J&N 400-52039
Bosch AL6513X
Chrysler 56005685, 56005685AB
Delco 19134108, 334-1115, DRA3788
Denso 121000-3450, 121000-3451, 121000-3452, 121000-3600, 121000-3601, 121000-3602, 210-0130, 211-0107, 9712109-345
Lester 13341
PIC Picture ID 290-301
Substitutes:
J&N 400-52039
Bosch AL6509X
Wilson 90-29-5122
References:
Wilson 90-29-5122
DXA488 ANJ215 658347
WAI New 13341N
WAI Old 1-1511-01ND, 1-1511-01ND-2
WAI To Be Superseded 13341R
ACE Electric CA-13341
ACE Zorkos CA13341N
Alltech 326-13341
American Power Systems APS13341
Andre Niermann 023390
ARC A1598N
Armature G Roy 13341
Arrow Automotive Industries 29-2197
Ashdown Ingram RXA488
Atelier Dynamo A13341
Auto Electric Suppliers 13341, 13341N
Autoelectro AEA2239
Beck Arnley New 188-0560
Beck Arnley Remanufactured 186-0560
Bepco 80-13341
Bosch Remanufactured AL6509X
Bosch Service Europe 0 986 080 630
Bowers BAO3095
Canadian Tire 0195476, 0197869, 0198148
CASCO CAL40272AS
Champion Parts Rebuilders 13-0933
Chrysler 56005685, 56005685AB, 59005685
CPC 13341
CPI KIT
Delphi RM4119
Denso 121000-3450, 121000-3452, 121000-3600
DNS A13245
DRI A/S Denmark 534003902, 534015902
DuBois 913341
EGI A-13341
Elpar Industries 020803603
Excel 10002
HC Parts UA960
Hella 8EL 012 429-661, 8EL 732 747-001
Hollander 754B
Knight Rebuilding A8811
Lester 13341
Lucas Electrical Europe LRA01133
Lucas Remanufactured A1405
Metro Auto Industrial 133412
Metron 13341
Minnpar 47-2025
Minnpar Old 6882025
Mondial 60-903-10
Mondial New 60-903-10N
Nastra A1598N
Nastra New 891599
Nastra Velocity EA1598N
New Tech N13341
Our Part Number 13341N, 13341R
Part # 13341
PASCO A-1000301
Power Select 13341N, 13341R
Powerite Automotive 13341
Precision Parts & Remanufacturing DOA332
Quality Rebuilders 14869
Raw Power 13341N, 13341R
Rayloc 13-8605, 13-8613, 138613
Rayloc New 1N8605, 1N8613
Real 20132169
Reliance 41652
Road Warrior 13341N, 13341R
Rotex 13341
Sovereign SA022
Stratoline 80-13341
Suncoast 13245
Techno CVC IMP-A1598N
TSA 13341N
UCP New 13341N
UCP Remanufactured 13341
Unit Parts 5511-6
USA Industries A2431
Wood Auto Supplies ALT30327
Zorko 13341, 13341N
Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 12 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.4) | 11 mm |
| Length (L.1) | 186 mm |
| Mount Inside Length or Pad Mount C-C (C) | 55.5 mm |
| OEM Product | No |
| Plug Code | PL_9102 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 34 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DODGE | Dakota 2.5 | 01.1997-01.1997 | |
| DODGE | Dakota 2.5 | 01.1998-01.1998 | |
| JEEP | Cherokee 2.5 | 01.1991-01.1993 | |
| JEEP | Cherokee 2.5 | 01.1994-01.1997 | |
| JEEP | Cherokee 2.5 | 01.1998-01.1998 | |
| JEEP | Cherokee 4.0 | 01.1991-01.1992 | |
| JEEP | Cherokee 4.0 | 01.1991-01.1993 | |
| JEEP | Cherokee 4.0 | 01.1991-01.1996 | |
| JEEP | Cherokee 4.0 | 01.1993-01.1996 | |
| JEEP | Cherokee 4.0 | 01.1994-01.1997 | |
| JEEP | Cherokee 4.0 | 01.1996-01.1996 | |
| JEEP | Cherokee 4.0 | 01.1997-01.1997 | |
| JEEP | Cherokee 4.0 | 01.1998-01.1998 | |
| JEEP | Comanche 2.5 | 01.1991-01.1991 | |
| JEEP | Comanche 2.5 | 01.1991-01.1992 | |
| JEEP | Comanche 4.0 | 01.1991-01.1992 | |
| JEEP | Grand Cherokee 4.0 | 01.1993-01.1993 | |
| JEEP | Grand Cherokee 4.0 | 01.1993-01.1997 | |
| JEEP | Grand Cherokee 4.0 | 01.1994-01.1995 | |
| JEEP | Grand Cherokee 4.0 | 01.1995-01.1997 | |
| JEEP | Grand Cherokee 4.0 | 01.1998-01.1998 | |
| JEEP | Wagoneer 2.5 | 01.1991-01.1991 | |
| JEEP | Wagoneer 2.5 | 01.1991-01.1993 | |
| JEEP | Wagoneer 2.5 | 01.1991-01.1994 | |
| JEEP | Wagoneer 2.5 | 01.1994-01.1997 | |
| JEEP | Wagoneer 2.5 | 01.1995-01.1995 | |
| JEEP | Wagoneer 4.0 | 01.1991-01.1992 | |
| JEEP | Wagoneer 4.0 | 01.1991-01.1993 | |
| JEEP | Wagoneer 4.0 | 01.1991-01.1994 | |
| JEEP | Wagoneer 4.0 | 01.1991-01.1997 | |
| JEEP | Wagoneer 4.0 | 01.1992-01.1992 | |
| JEEP | Wagoneer 4.0 | 01.1994-01.1995 | |
| JEEP | Wagoneer 4.0 | 01.1997-01.1997 | |
| JEEP | Wrangler 2.5 | 01.1998-01.1998 | |
| JEEP | Wrangler 4.0 | 01.1998-01.1998 |
Alternatives >>>
A6093 - Has 4 groove pulley which can be swapped from original unit
Reference Information
13341R ALN0960 13341N 59005685 UD16879A 121000-3602 27-3603 LRA1133 835.510.090 20132272BN STX100403R A-8332 113063 90-29-5122N ALT6084 CGB-13788 56005684 56005685 56005685AB LRA01133 446842 STX100403 121000-3450 121000-3452 90-29-5122Video/Publications
