Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 918.49 including GST
NZ$ 798.69 excluding GST
or four payments of $229.62
with
Learn More
each
SGP-C11009
S3034
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
101164 101164P 112227 20479406BN 254261 254261P 33576 45-2488 45-3425 455723 6010654 77723828 8212249 8528 88212249 8EA737677-001 CS1164 CST10654 CST10654AS CST10654ES CST10654GS CST10654OS CST10654RS CST15604AS D13HP603 D13HP613 D13HP709 DRS3815 EAA-121338 LRS01935 M009T80071 M009T80271 M009T80272 M105R3032SE M9T80071 M9T80271 M9T80272 ND172 S3034 STR54106 STR71075Specifications
| Kilowatt | 8 kW |
| Length (L.1) | 450 mm |
| Mount Hole Center - Center (O.1) | 21 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 127 mm |
| Mount Hole Center - Center (O.4) | 107 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| Mount Hole Diameter (C.4) | 13.5 mm |
| No./Mount holes | 4 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 48 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | VALEO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| RENAULT V.I. | Magnum 400.18 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 400.24 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 400.26 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 440.18 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 440.24 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 440.26 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 480.18 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 480.24 12.0 | 05.2000- | |
| RENAULT V.I. | Magnum 480.26 12.0 | 05.2000- |
Reference Information
CST10654OS 5001843276 MAV376110 ANM16035X 5010306000 5001853716 254261P STRS056 CST10654GS CS1497 D13HP603 33576 EAA-121338 8528 STR71075 5001854179 6010654 5001844132 101164 254261 77723828 D13HP613 101164P CS1164 114100 5010508382 CST15604AS M105R3032SE STR0094 LRS01935 ND172 88212249 112227 8212249 CST10654 45-2488 M9T80071 5010306701 M9T80271 M9T80272 220259 5001846324 MAV126540 5010217957 5010480432 D13HP709 455723 CGB-90271 M009T80071 5010853716 CST10654RS M009T80271 M009T80272 5010306631 220568 220567 DRS3815 CST10654AS 45-3425 20479406BN CST10654ES S3034 LRS1935 5001014212 STR54106 S24MH0083A2 8EA737677-001 5010270642Video/Publications
