Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 262.73 including GST
NZ$ 228.46 excluding GST
or four payments of $65.68
with
Learn More
each
S0718S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
F000AL0111Associated Numbers
115594 190.595.092 19662N 220996 25-4491 255080 28100-0L070 28100-0L072 28100-0L080 28100-0L081 6010A05 9503 AEY3818 CST10A05 CST10A05AS CST10A05ES CST10A05GS CST10A05OS CST10A05RS DRS1141 DS2251 EAA-123091 F000AL0111 F004A94008 F004A94011 LRS03818 STB4186 STR50693 UD01217SSpecifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 250.5 mm |
| Mount Hole Center - Center (O.1) | 129 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 18 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.5 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Fortuner 3.0 | [1KD-FTV] | 06.2004- |
| TOYOTA | Hilux 2.5 | [2KD-FTV] | 12.2007- |
| TOYOTA | Hilux 2.5 D-4D | [2KD-FTV] | 06.2006- |
| TOYOTA | Hilux 2.5 D-4D 4x4 | [2KD-FTV] | 12.2007- |
| TOYOTA | Hilux 3.0 | [1KD-FTV] | 10.2006- |
| TOYOTA | Hilux 3.0 4x4 | [1KD-FTV] | 08.2005-09.2006 |
Reference Information
28100-0L070 255080 9503 F004A94008 281000L082 28100-0L072 STB4186 STX210248R CST10A05RS F000AL0111 STX210245 STX210248 220996 6010A05 190.595.092.010 S0718S UD01217S 190.595.092.215 CST10A05 25-4491 DS2251 5010407 PRSF949 190.595.092 S12BH0337A2 19662N DRS1141 STR50693 28100-0L080 CST10A05GS 28100-0L081 STR1246 STX210245R 28100-0L082 CST10A05OS LRS3818 STRF949 F004A94011 332158 AEY3818 115594 LRS03818 CST10A05AS 190.595.092.280 CST10A05ES 190.595.092.460Video/Publications
