or four payments of $130.66
with
Learn More
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
104210-1800 104210-2870 11087 37300-3C510 37300-3C520 90-29-5784 UD11383A UD14161A
0986CN6047 Bosch ruil
0986CR6047 Bosch ruil
0986CR6085 Bosch ruil
0986UR6085 Bosch ruil
1042101800 Denso
1042102870 Denso
11686 Lester
255539150 PSH
373003C510 Kia
373003C520 Kia
AL4088N Bosch (USA)
AL4088X Bosch (USA)
AL4090X Bosch (USA)
104210-287
Substitutes:
JANNCO 400-52438R
Wilson 90-29-5784
References:
Denso 104210-287
Hyundai 37300-3C510
PIC Picture ID 290-5579
JANNCO 400-52438R
Remy Light Duty 11087
References:
JANNCO 400-52438R
Denso 104210-1800, 104210-2870
Hyundai 37300-3C510, 37300-3C520
Lester 11591
PIC Picture ID 290-5579, 290-5580
Remy Light Duty 11087
dxa4107 ANJ304 65-85103
UD11383A AS-PL
UD14161A AS-PLList
11087 DELCO
104210-1800 DENSOList
104210-2870 DENSOList
37300-3C510 HYUNDAI / KIAList
37300-3C520 HYUNDAI / KIA
90-29-5784 WILSON
References:
Arrowhead AND0630, VND0630
J&N 400-52438
Denso 104210-1800, 104210-2870
Hyundai 37300-3C510, 37300-3C520
Lester 11591, 11686
PIC Picture ID 290-5579, 290-5580
Remy Light Duty 11087
Wilson 90-29-5784
JANNCO 400-52438R
Wilson 90-29-5784
0986CN6047 Bosch ruil
0986CR6047 Bosch ruil
0986CR6085 Bosch ruil
0986UR6085 Bosch ruil
1042101800 Denso
1042102870 Denso
11686 Lester
255539150 PSH
373003C510 Kia
373003C520 Kia
AL4088N Bosch (USA)
AL4088X Bosch (USA)
AL4090X Bosch (USA)
References:
JANNCO 400-52438R
Wilson 90-29-5784
Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Length (L.1) | 174 mm |
| Mount Inside Length or Pad Mount C-C (C) | 43.5 mm |
| OEM Product | No |
| Plug Code | PL_4005 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 53 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Azera 3.3 V6 | 01.2012- | |
| HYUNDAI | Genesis 3.8 V6 | 01.2012- | |
| HYUNDAI | Santa Fe 3.3 V6 | 01.2013- | |
| KIA | Cadenza 3.3 V6 | 01.2014- | |
| KIA | Sedona 3.5 V6 | 01.2011- | |
| KIA | Sorento 3.5 V6 | 01.2011- |
Reference Information
UD11383A 37300-3C520 37300-3C510 11686N 11087 104210-2870 UD14161A 90-29-5784 104210-1800Video/Publications
A6273Related Items
