Associated Numbers
101210-0940 11.2046M 13222929 28-5577 553506RID 6204256 63377496 9462 AEK2958 CA2046IR DAN1055 LRA02963 UD11969(DENSO)ASpecifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 34.5 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M10x1.5 mm |
Diameter (D.4) | M10x1.5 mm |
Length (L.1) | 186 mm |
Mount Inside Length or Pad Mount C-C (C) | 57 mm |
OEM Product | Yes |
Plug Code | PL_2200 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley Grooves | 5 qty |
Pulley Outside Diameter (O.D.1) | 54 mm |
Pulley to Mount Distance (A) | 54 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Agila 1.0 | [Z10XEP] | 08.2003-12.2007 |
OPEL | Agila 1.0 12V | [Z10XE] | 09.2000-12.2007 |
OPEL | Agila 1.2 16V | [Z12XE] | 09.2000-12.2007 |
OPEL | Agila 1.2 16V Twinport | [Z12XEP] | 07.2004-12.2007 |
OPEL | Astra 1.2 | [Z12XEP] | 08.2005-10.2010 |
OPEL | Astra 1.4 | [Z14XEL] | 04.2004-10.2004 |
OPEL | Astra 1.4 | [Z14XEL] | 08.2004-10.2010 |
OPEL | Astra 1.4 | [Z14XEP] | 01.2009- |
OPEL | Astra 1.4 | [Z14XEP] | 02.2007-06.2010 |
OPEL | Astra 1.4 | [Z14XEP] | 03.2004-10.2010 |
OPEL | Astra 1.4 | [Z14XEP] | 08.2004-10.2010 |
OPEL | Astra 1.4 EcoTec | [Z14XEP] | 12.2004-12.2012 |
OPEL | Astra 1.4 GTC | [Z14XEL] | 03.2005-10.2010 |
OPEL | Astra 1.4 GTC | [Z14XEP] | 03.2005-10.2010 |
OPEL | Astra 1.4 LPG | [Z14XEP] | 08.2009-10.2010 |
OPEL | Astra 1.4 TwinTop | [Z14XEP] | 10.2005-10.2010 |
OPEL | Corsa 1.0 | [Z10XE] | 09.2000-06.2003 |
OPEL | Corsa 1.0 | [Z10XEP] | 06.2003-12.2009 |
OPEL | Corsa 1.2 | [A12XEL] | 01.2010-08.2014 |
OPEL | Corsa 1.2 | [A12XEL] | 12.2009-08.2014 |
OPEL | Corsa 1.2 | [A12XER] | 06.2010-08.2014 |
OPEL | Corsa 1.2 | [A12XER] | 12.2009-08.2014 |
OPEL | Corsa 1.2 | [Z12XE] | 09.2000-12.2009 |
OPEL | Corsa 1.2 | [Z12XEP] | 07.2005-06.2006 |
OPEL | Corsa 1.2 | [Z12XEP] | 07.2006-08.2014 |
OPEL | Corsa 1.2 | [Z12XEP] | 08.2006-08.2014 |
OPEL | Corsa 1.2 16V | [Z12XE] | 09.2000-07.2003 |
OPEL | Corsa 1.2 LPG | [A12XER] | 06.2011-08.2014 |
OPEL | Corsa 1.2 LPG | [Z12XEP] | 08.2006-08.2014 |
OPEL | Corsa 1.2 LPG | [Z12XEP] | 09.2009-12.2011 |
OPEL | Corsa 1.2 Twinport | [Z12XEP] | 07.2004-12.2009 |
OPEL | Corsa 1.4 | [A14XEL] | 09.2009-08.2014 |
OPEL | Corsa 1.4 | [A14XER] | 12.2009-08.2014 |
OPEL | Corsa 1.4 | [Z14XEP] | 07.2006-08.2014 |
OPEL | Corsa 1.4 | [Z14XEP] | 08.2003-06.2012 |
OPEL | Corsa 1.4 LPG | [Z14XEP] | 08.2006-12.2011 |
OPEL | Corsa 1.4 Twinport | [Z14XEP] | 06.2003-12.2009 |
OPEL | Meriva 1.4 16V Twinport | [Z14XEP] | 07.2004-05.2010 |
OPEL | Meriva 1.4 16V Twinport LPG | [Z14XEP] | 07.2004-05.2010 |
OPEL | Tigra 1.4 TwinTop | [Z14XEP] | 06.2004-12.2010 |
TOYOTA | RAV4 2.0 4WD | [3S-FE] | 12.1997-06.2000 |
Reference Information
0986083580 UD11969(DENSO)A DAN1055 2030224.1 1202438 114249 DRA0484 6204256 23958R 9462 LRA2963 13222929 ZX13222929 101210-0940 210740 A6268(DENSO) PRAL831 63377496 9090641 12090459 CAL30224GS CGB-85577 LRA02963 135.571.070.261 57490 DRA0484X 553506RID CA2046IR ALTL831 89215421 28-5577 ZX 11.2046M 95519874Video/Publications
A6268(DENSO)Related Items
