Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 706.25 including GST
NZ$ 614.13 excluding GST
or four payments of $176.56
with
Learn More
each
A5295
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
0986080660 114859 20130N 2035188 210520 225.533.180 23857R 2543457 2543457A 2607732 28-4973 301920RIV 56547528ON80 5702F4 5702G2 5705AX 5705EE 5705JF 89212430 8EL011712-341 8EL738211-991 944390904470 9646065180 964638828 9646388280 96547528 9654752880 9661544880 9688085380 A004TJ0081 A004TJ0081A A004TJ0081C A004TJ0084 A004TJ0084A A004TJ0084B A004TJ0084C A4TJ0081 A4TJ0081A A4TJ0081B A4TJ0081C A4TJ0084 A4TJ0084A A4TJ0084B A4TJ0084C AEK2857 ALM1920 ALV1920 CA1920IR CAL35188 CAL35188AS CAL35188ES CAL35188GS CAL35188OS CAL35188RS DRA0142 EAA-241114 FG18S017 FG18S048 LRA02857 MITA4TJ0084 UD11047A VALFG18S017Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 21 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Diameter (D.4) | M10x1.5 mm |
| Length (L.1) | 185 mm |
| Mount Inside Length or Pad Mount C-C (C) | 45.5 mm |
| OEM Product | No |
| Plug Code | PL_2401 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 42.5 mm |
| Pulley Type | CLUTCH |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | Berlingo 1.6 HDi | [9HN(DV6ETED4)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HS(DV6TED4BU)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HT(DV6BTED4)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HT(DV6BUTED4)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HX(DV6ATED4)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HX(DV6ATED4)] | 07.2005- |
| CITROEN | Berlingo 1.6 HDi | [9HZ(DV6TED4)] | 04.2008- |
| CITROEN | Berlingo 1.6 HDi | [9HZ(DV6TED4)] | 08.2005- |
| CITROEN | Berlingo 1.6 HDi 90 | [9HX(DV6ATED4)] | 04.2008- |
| CITROEN | C4 1.6 HDi Grand Picasso | [9HY(DV6TED4)] | 10.2006- |
| CITROEN | C4 1.6 HDi Grand Picasso | [9HZ(DV6TED4)] | 10.2006- |
| CITROEN | C4 1.6 HDi Picasso | [9HY(DV6TED4)] | 02.2007- |
| CITROEN | C4 1.6 HDi Picasso | [9HZ(DV6TED4)] | 02.2007- |
| CITROEN | C4 2.0 HDi | [RHF(DW10BTED4)] | 07.2008- |
| CITROEN | C4 2.0 HDi | [RHR(DW10BTED4)] | 11.2004- |
| CITROEN | C4 2.0 HDi Grand Picasso | [RHJ(DW10BTED4)] | 10.2006- |
| CITROEN | C4 2.0 HDi Grand Picasso | [RHR(DW10BTED4)] | 10.2006- |
| CITROEN | C4 2.0 HDi Picasso | [RHJ(DW10BTED4)] | 02.2007- |
| CITROEN | C4 2.0 HDi Picasso | [RHR(DW10BTED4)] | 02.2007- |
| CITROEN | C5 1.6 HDi | [9HZ(DV6TED4)] | 02.2008- |
| CITROEN | C5 2.0 HDi | [RHF(DW10BTED4)] | 02.2008- |
| CITROEN | C5 2.0 HDi | [RHR(DW10BTED4)] | 02.2008- |
| CITROEN | C5 2.0 HDi | [RHR(DW10BTED4)] | 09.2004- |
| CITROEN | C5 2.2 HDi | [4HP(DW12BTED4)] | 05.2006- |
| CITROEN | C5 2.2 HDi | [4HR(DW12BTED4)] | 05.2006- |
| CITROEN | C5 2.2 HDi | [4HT(DW12BTED4)] | 02.2008- |
| CITROEN | C5 2.2 HDi | [4HT(DW12BTED4)] | 04.2006- |
| CITROEN | C5 2.2 HDi 165 | [4HP(DW12BTED4)] | 02.2008- |
| CITROEN | C6 2.2 HDi | [4HP(DW12BTED4)] | 06.2006- |
| CITROEN | C6 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
| CITROEN | C8 2.0 HDi | [RHK(DW10UTED4)] | 02.2007- |
| CITROEN | C8 2.0 HDi | [RHR(DW10BTED4)] | 03.2006- |
| CITROEN | C8 2.2 HDi | [4HP(DW12BTED4)] | 06.2007- |
| CITROEN | C8 2.2 HDi | [4HR(DW12BTED4)] | 06.2007- |
| CITROEN | C8 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
| CITROEN | Dispatch 2.0 HDi | [RHR(DW10BTED4)] | 01.2007-12.2016 |
| CITROEN | Jumpy 2.0 HDi | [RHK(DW10UTED4)] | 01.2007- |
| CITROEN | Jumpy 2.0 HDi | [RHR(DW10BTED4)] | 01.2007- |
| FIAT | Scudo 2.0 Diesel | [DW10BTED4] | 01.2007- |
| FIAT | Scudo 2.0 Multijet | [RH02] | 04.2011- |
| FIAT | Scudo 2.0 Multijet | [RH02] | 05.2011- |
| FIAT | Scudo 2.0 Multijet | [RHH] | 01.2007- |
| FIAT | Scudo 2.0 Multijet | [RHK] | 01.2007- |
| FIAT | Scudo 2.0 Multijet | [RHR] | 01.2007- |
| FIAT | Scudo 2.0 Multijet 4x4 | [RH02] | 04.2011- |
| FIAT | Ulysse 2.0 Multijet | [RHK] | 05.2006- |
| FIAT | Ulysse 2.0 Multijet | [RHR] | 05.2006- |
| FIAT | Ulysse 2.2 JTD | [4HP] | 03.2008- |
| FIAT | Ulysse 2.2 JTD | [4HR] | 03.2008- |
| FIAT | Ulysse 2.2 JTD | [4HW(DW12ATED4)] | 08.2002- |
| FIAT | Ulysse 2.2 Multijet | [4HT] | 03.2008- |
| LANCIA | Phedra 2.0 Multijet | [RHR(DW10BTED4)] | 07.2006- |
| LANCIA | Phedra 2.2 JTD | [4HP] | 04.2006- |
| LANCIA | Phedra 2.2 JTD | [4HR] | 04.2006- |
| LANCIA | Phedra 2.2 JTD | [4HW(DW12ATED4)] | 09.2002- |
| LANCIA | Phedra 2.2 Multijet | [4HS] | 03.2008- |
| LANCIA | Phedra 2.2 Multijet | [4HT] | 03.2008- |
| PEUGEOT | 3008 1.6 HDi | [9HZ(DV6TED4)] | 01.2009- |
| PEUGEOT | 307 2.0 HDi FAP | [RHR(DW10BTED4)] | 02.2004- |
| PEUGEOT | 407 2.0 HDi | [RHR(DW10BTED4)] | 09.2008-12.2009 |
| PEUGEOT | 407 2.0 HDi | [RHR(DW10BTED4)] | 10.2005- |
| PEUGEOT | 407 2.0 HDi FAP | [RHR(DW10BTED4)] | 05.2004- |
| PEUGEOT | 407 2.2 HDi | [4HP(DW12BTED4)] | 06.2008- |
| PEUGEOT | 407 2.2 HDi FAP | [4HT(DW12BTED4)] | 05.2006- |
| PEUGEOT | 407 SW 2.0 HDi | [RHL(DW10BTED4)] | 11.2004- |
| PEUGEOT | 407 SW 2.2 HDi | [4HP(DW12BTED4)] | 06.2008- |
| PEUGEOT | 607 2.0 HDi | [RHR(DW10BTED4)] | 09.2005- |
| PEUGEOT | 607 2.2 HDi FAP | [4HT(DW12BTED4)] | 05.2006- |
| PEUGEOT | 807 2.0 HDi | [DW10UTED4] | 02.2006- |
| PEUGEOT | 807 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
| PEUGEOT | Expert 2.0 HDi | [RHK(DW10UTED4)] | 01.2007- |
| PEUGEOT | Expert 2.0 HDi | [RHR(DW10BTED4)] | 01.2007- |
| PEUGEOT | Expert 2.0 HDi Tepee | [RHK(DW10UTED4)] | 01.2007- |
| PEUGEOT | Expert 2.0 HDi Tepee | [RHR(DW10BTED4)] | 01.2007- |
| PEUGEOT | Partner 1.6 HDi | [9HT(DV6BTED4)] | 01.2009- |
| PEUGEOT | Partner 1.6 HDi | [9HX(DV6ATED4)] | 01.2009- |
| PEUGEOT | Partner 1.6 HDi | [9HX(DV6ATED4)] | 02.2006- |
| PEUGEOT | Partner 1.6 HDi | [9HZ(DV6TED4)] | 04.2008- |
| PEUGEOT | Partner 1.6 HDi Tepee | [9HZ(DV6TED4)] | 04.2008- |
Reference Information
CAL35188GS ALTL361 CAL35188OS ALV1920 442083 5705EE 9.44391E+11 A004TJ0081A 56547528ON80 DRA0142 FG18S017 UD11047A 5705AX 9654752880 ALM1920 LRA2857 A004TJ0081AM A4TJ0084AM A4TJ0081A A5295 2035188 CAL35188 114859 8EL738211-991 0986080660 A004TJ0084B 9646065180 A004TJ0084A ALT0118 A004TJ0084C A12VA0124A2 5705JF 5705NG ALT5404 A4TJ0081 57056K A4TJ0084C A4TJ0084 A4TJ0084A A4TJ0084B 96547528 EAA-241114 9646388280 MD171502 89212430 CAL35188ES LRA02857 23857R 9688085380 2543457 A4TJ0081AM A004TJ0084AM 28-4973 STX100675 CA1920IR 8EL011712-341 210520 301920RIV 5702F4 VALFG18S017 MITA4TJ0084 CAL35188AS 5702G2 AEK2857 2543457A ALT371880 A4TJ0081B A4TJ0081C FG18S048 MM317603 225.533.180 CAL35188RS 2607732 A004TJ0084 9661544880 20130N A004TJ0081C 964638828 A004TJ0081 A004TJ0081B K9661544880 5702K8Video/Publications
A5295Related Items
