Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 302.77 including GST
NZ$ 263.28 excluding GST
or four payments of $75.69
with
Learn More
each
A4043
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
63321826Associated Numbers
0986049231 11.1558 11.1558M 11.1698M 113943 20104301BN 20104301OE 20110326 2030103 20315RW 28-3750 301189RI 301558RI 301558RIM 301697RIM 32321859 4497 46544329 46763533 46763534 46765838 46782213 56822 60816045 60816557 63321497 63321501 63321804 63321805 63321806 63321826 89213550 8EL011710-501 8EL737812-001 9090168 9213550 A4043 AEC1558 ALT12065 CA1558IR CAL30103 CAL30103AS CAL30103ES CAL30103GS CAL30103OS CAL30103RS DAN501 DAN635 DRA3768 DRA4206 EAA-221022 GA321826-A GA321826M-R LRA01887 SB014 SB151Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 17 mm |
| Diameter (D.1) | 12.5 mm |
| Diameter (D.2) | 11.5 mm |
| Diameter (D.3) | 12.5 mm |
| Length (L.1) | 185 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54.5 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Type | NO PULLEY |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | 145 1.9 JTD | [AR32302] | 02.1999-01.2001 |
| ALFA ROMEO | 147 1.9 JTD | [937A2.000] | 11.2000- |
| ALFA ROMEO | 147 1.9 JTD 16V | [192A5.000] | 09.2002- |
| ALFA ROMEO | 147 1.9 JTDM 16V | [937A5.000] | 10.2004- |
| ALFA ROMEO | 156 1.9 JTD | [AR32302] | 09.1997-10.2000 |
| ALFA ROMEO | Alfa 146 1.9 JTD | [AR32302] | 02.1999-01.2001 |
| FIAT | Brava 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Brava 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Bravo 1.9 JTD | [182B4.000] | 12.1998-10.2001 |
| FIAT | Bravo 1.9 JTD | [182B9.000] | 09.2000-10.2001 |
| FIAT | Doblo 1.9 Diesel | [223A6.000] | 03.2001- |
| FIAT | Doblo 1.9 Diesel Multijet | [186A9.000] | 10.2005- |
| FIAT | Doblo 1.9 JTD | [182B9.000] | 10.2001- |
| FIAT | Doblo 1.9 JTD | [182B9.000] | 10.2001-01.2004 |
| FIAT | Doblo 1.9 JTD | [223A7.000] | 11.2002-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B1.000] | 11.2002-09.2005 |
| FIAT | Doblo 1.9 JTD | [223B2.000] | 10.2001- |
| FIAT | Idea 1.9 JTD | [188B2.000] | 01.2004- |
| FIAT | Marea 1.9 JTD | [182B4.000] | 04.1999-01.2001 |
| FIAT | Marea 1.9 JTD | [186A6.000] | 01.2001- |
| FIAT | Marengo 1.9 JTD | [186A6.000] | 08.2000-09.2002 |
| FIAT | Multipla 1.9 JTD | [182B4.000] | 04.1999- |
| FIAT | Multipla 1.9 JTD | [186A6.000] | 03.2001- |
| FIAT | Multipla 1.9 JTD | [186A8.000] | 07.2002- |
| FIAT | Multipla 1.9 JTD | [186A9.000] | 04.2002- |
| FIAT | Punto 1.9 JTD | [188A2.000] | 09.1999- |
| FIAT | Punto 1.9 JTD | [188A7.000] | 06.2001-06.2003 |
| FIAT | Punto 1.9 JTD | [188B2.000] | 06.2003- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A8.000] | 09.2005- |
| FIAT | Stilo 1.9 Diesel Multijet | [192A9.000] | 09.2005- |
| FIAT | Stilo 1.9 JTD | [192A1.000] | 01.2003- |
| FIAT | Stilo 1.9 JTD | [192A3.000] | 01.2003- |
| FIAT | Stilo 1.9 JTD | [192A3.000] | 10.2001- |
| FIAT | Stilo 1.9 JTD | [192B1.000] | 01.2004- |
| FIAT | Stilo 1.9 JTD | [192B5.000] | 09.2004- |
| FIAT | Stilo 1.9 JTD | [937A7.000] | 07.2005- |
| LANCIA | Lybra 1.9 JTD | [937A2.000] | 05.2001- |
| LANCIA | Lybra 1.9 JTD | [AR32302] | 07.1999-09.2000 |
| LANCIA | Lybra 1.9 JTD | [AR37101] | 09.2000- |
| LANCIA | Lybra 1.9 JTD SW | [AR37101] | 09.2000- |
| LANCIA | Musa 1.9 Diesel Multijet | [188B2.000] | 10.2004- |
Reference Information
20104301RE NPANAL1406 ALT90023 71721092 CA1558IR 11.1698M A4043 MAN1127 SB014 AEC1558 ALTS916 CA1698IR DAN501 CAL30103OS STX100029 56822 AAL1406 CAL30103GS DRA4206 STX100127R 20104301BN 8EL011710-501 2030103 63321501 28-3750 GA321826M-R 51859053 60816557 STX100029R 301697RIM 2030103.1 2030103.4 20315RW 2030103.0 63321497 RNL63321804NP ALT321860 60816045 11.1558M SB151 CAL30103 301558RI 63321805 63321806 0986049231 71794788 CAL30103AS STX100068R 63321804 ALT9025 113336 4497 CAL30103RS 46782212 46782213 A12MA1197A2 46765838 LRA1887 46544329 ALT2200 ALT2280A 46763533 11.1558 46763534 ALT2280 ALTL129 210863 ALT321480 20104301OE 8EL737812-001 301558RIM STX100068 32321859 63321826 301189RI GA321826-A LRA01887 DAN635 A12DE0003A2 ANM36426X DRA3768 89213550 9090168 ALT12065 210263 20110326 STX102027 9213550 46554408 113943 60815953 STX100127 CAL30103ES 46774430 RNL63321804 STA0367R 71721106Video/Publications
