Associated Numbers
11.1975 11.1975M 2015336 20179633OE 20453N 2543206 2543564 2605275 28-5767 301975RI 301975RIV 4697 57139 8200410681 8200667614 8200772726 8EL738211-891 9090544 9212834 A3103 AEK3155 ALT14220 CA1975IR CAL15336GS EAA-221085 LRA03155 SB207 TG11C041 TG11C066 TG11C069Specifications
Amp | 110 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Length (L.1) | 193 mm |
Mount Inside Length or Pad Mount C-C (C) | 61 mm |
OEM Product | No |
Plug Code | PL_2800 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 38 mm |
Pulley Type | CLUTCH |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
DACIA | Logan 1.6 16V Flexifuel | [K4M696] | 07.2010- |
PEUGEOT | 307 1.6 HDI 110 | [9HY(DV6TED4)] | 11.2003-12.2007 |
PEUGEOT | 307 1.6 HDI 110 | [9HZ(DV6TED4)] | 11.2003-12.2007 |
PEUGEOT | 308 1.6 16V | [5FW(EP6)] | 09.2007-10.2014 |
PEUGEOT | 308 1.6 16V | [EP6] | 09.2007-10.2014 |
RENAULT | Clio 1.4 16V | [K4J710] | 02.2000-07.2008 |
RENAULT | Clio 1.4 16V | [K4J711] | 02.2000-07.2008 |
RENAULT | Clio 1.4 16V | [K4J712] | 02.2000-07.2008 |
RENAULT | Clio 1.4 16V | [K4J712] | 10.1999-09.2004 |
RENAULT | Clio 1.4 16V | [K4J713] | 02.2000-07.2008 |
RENAULT | Clio 1.4 16V | [K4J713] | 10.1999-09.2004 |
RENAULT | Clio 1.4 16V | [K4J715] | 02.2000-07.2008 |
RENAULT | Clio 1.4 16V | [K4J780] | 06.2005-12.2012 |
RENAULT | Clio 1.4 16V Grandtour | [K4J780] | 11.2007-12.2012 |
RENAULT | Clio 1.5 dCi | [K9K714] | 06.2005-12.2012 |
RENAULT | Clio 1.5 dCi | [K9K740] | 06.2005-12.2010 |
RENAULT | Clio 1.5 dCi | [K9K752] | 05.2005-07.2010 |
RENAULT | Clio 1.5 dCi | [K9K752] | 06.2005-12.2012 |
RENAULT | Clio 1.5 dCi | [K9K764] | 06.2005-12.2014 |
RENAULT | Clio 1.5 dCi | [K9K766] | 06.2005-12.2012 |
RENAULT | Clio 1.5 dCi | [K9K768] | 06.2005-12.2012 |
RENAULT | Clio 1.5 dCi | [K9K768] | 10.2005-07.2010 |
RENAULT | Clio 1.5 dCi | [K9K774] | 06.2005-12.2014 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K714] | 11.2007-12.2012 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K752] | 11.2007-12.2012 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K764] | 02.2008-12.2012 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K766] | 11.2007-12.2012 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K768] | 11.2007-12.2012 |
RENAULT | Clio 1.5 dCi Grandtour | [K9K774] | 02.2008-12.2012 |
RENAULT | Clio 1.6 16V | [K4M708] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M740] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M742] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M743] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M744] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M745] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M748] | 09.1998-04.2005 |
RENAULT | Clio 1.6 16V | [K4M800] | 06.2005-12.2014 |
RENAULT | Clio 1.6 16V | [K4M801] | 06.2005-12.2014 |
RENAULT | Clio 1.6 16V | [K4M804] | 06.2005-10.2007 |
RENAULT | Clio 1.6 16V Grandtour | [K4M800] | 11.2007-12.2012 |
RENAULT | Clio 1.6 16V Grandtour | [K4M801] | 11.2007-12.2012 |
RENAULT | Clio 1.6 16V Grandtour | [K4M862] | 11.2007-12.2012 |
RENAULT | Clio 1.6 16V GT | [K4M862] | 06.2009-12.2014 |
RENAULT | Fluence 1.6 16V | [K4M838] | 02.2010- |
RENAULT | Fluence 1.6 16V | [K4M839] | 02.2010- |
RENAULT | Grand Kangoo 1.6 16V | [K4M830] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V | [K4M831] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V | [K4M834] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V | [K4M835] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V | [K4M836] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V Flex | [K4M834] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V Flex | [K4M835] | 02.2008- |
RENAULT | Grand Kangoo 1.6 16V LPG | [K4M834] | 12.2008- |
RENAULT | Grand Kangoo 1.6 16V LPG | [K4M835] | 12.2008- |
RENAULT | Grand Kangoo 1.6 16V LPG | [K4M836] | 12.2008- |
RENAULT | Grand Modus 1.4 | [K4J770] | 12.2004- |
RENAULT | Grand Modus 1.4 | [K4J780] | 12.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K750] | 09.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K752] | 12.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K760] | 12.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K764] | 05.2005- |
RENAULT | Grand Modus 1.5 dCi | [K9K766] | 12.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K768] | 12.2004- |
RENAULT | Grand Modus 1.5 dCi | [K9K772] | 05.2007- |
RENAULT | Grand Modus 1.5 dCi 75 | [K9K770] | 10.2010- |
RENAULT | Grand Modus 1.5 dCi 90 | [K9K750] | 10.2010- |
RENAULT | Grand Modus 1.5 dCi 90 | [K9K770] | 10.2010- |
RENAULT | Grand Modus 1.6 | [K4M790] | 12.2004- |
RENAULT | Grand Modus 1.6 | [K4M791] | 12.2004- |
RENAULT | Grand Modus 1.6 | [K4M794] | 12.2004- |
RENAULT | Grand Modus 1.6 | [K4M800] | 12.2004- |
RENAULT | Grand Modus 1.6 | [K4M801] | 12.2004- |
RENAULT | Grand Scenic 1.5 dCi | [K9K728] | 04.2004-11.2008 |
RENAULT | Grand Scenic 1.6 | [K4M761] | 04.2004-08.2006 |
RENAULT | Grand Scenic 1.6 | [K4M782] | 04.2004-08.2006 |
RENAULT | Grand Scenic 1.6 16V | [K4M858] | 02.2009- |
RENAULT | Grand Scenic 1.6 E85 | [K4M866] | 02.2009- |
RENAULT | Kangoo 1.6 16V | [K4M706] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M730] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M750] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M752] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M753] | 06.2001- |
RENAULT | Kangoo 1.6 16V | [K4M830] | 02.2008- |
RENAULT | Kangoo 1.6 16V | [K4M831] | 02.2008- |
RENAULT | Kangoo 1.6 16V | [K4M834] | 02.2008- |
RENAULT | Kangoo 1.6 16V | [K4M835] | 02.2008- |
RENAULT | Kangoo 1.6 16V | [K4M836] | 02.2008- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M750] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 | [K4M753] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 Express | [K4M750] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 Express | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V 4x4 Express | [K4M753] | 10.2001- |
RENAULT | Kangoo 1.6 16V Bivalent | [K4M850] | 06.2005- |
RENAULT | Kangoo 1.6 16V Bivalent Express | [K4M850] | 06.2005- |
RENAULT | Kangoo 1.6 16V Express | [K4M706] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express | [K4M752] | 10.2001- |
RENAULT | Kangoo 1.6 16V Express | [K4M830] | 02.2008- |
RENAULT | Kangoo 1.6 16V Express | [K4M831] | 02.2008- |
RENAULT | Kangoo 1.6 16V Express | [K4M834] | 02.2008- |
RENAULT | Kangoo 1.6 16V Flex | [K4M834] | 02.2008- |
RENAULT | Kangoo 1.6 16V Flex | [K4M835] | 02.2008- |
RENAULT | Kangoo 1.6 16V Hi-Flex Hi-Flex | [K4M830] | 02.2008- |
RENAULT | Kangoo 1.6 16V LPG | [K4M834] | 12.2008- |
RENAULT | Kangoo 1.6 16V LPG | [K4M835] | 12.2008- |
RENAULT | Kangoo 1.6 16V LPG | [K4M836] | 12.2008- |
RENAULT | Kangoo 1.6 16V LPG Express | [K4M834] | 02.2008- |
RENAULT | Kangoo 1.6 Be Bop | [K4M] | 02.2009- |
RENAULT | Kangoo Be Bop 1.6 | [K4M830] | 02.2009- |
RENAULT | Laguna 1.6 16V | [K4M710] | 03.2001-05.2005 |
RENAULT | Laguna 1.6 16V | [K4M714] | 03.2001-05.2005 |
RENAULT | Laguna 1.6 16V | [K4M716] | 02.2005-08.2007 |
RENAULT | Laguna 1.6 16V | [K4M720] | 11.1997-03.2001 |
RENAULT | Laguna 1.6 16V | [K4M724] | 11.1997-03.2001 |
RENAULT | Laguna 1.6 16V | [K4M824] | 10.2007-12.2015 |
RENAULT | Laguna 1.6 16V Sport Tourer | [K4M710] | 03.2001-12.2007 |
RENAULT | Laguna 1.6 16V Sport Tourer | [K4M714] | 03.2001-12.2007 |
RENAULT | Laguna 1.6 16V Sport Tourer | [K4M716] | 02.2005-08.2007 |
RENAULT | Laguna 1.6 16V Sport Tourer | [K4M824] | 10.2007-12.2015 |
RENAULT | Logan 1.6 | [K4M690] | 04.2007- |
RENAULT | Logan 1.6 | [K4M694] | 04.2007- |
RENAULT | Logan 1.6 | [K4M696] | 04.2007- |
RENAULT | Logan 1.6 | [K4M697] | 04.2007- |
RENAULT | Logan 1.6 | [K4M698] | 04.2007- |
RENAULT | Megane 1.4 | [K4J730] | 09.2003- |
RENAULT | Megane 1.4 | [K4J732] | 09.2003- |
RENAULT | Megane 1.4 | [K4J740] | 09.2003- |
RENAULT | Megane 1.4 16V | [K4J700] | 03.1999-07.2003 |
RENAULT | Megane 1.4 16V | [K4J714] | 03.1999-07.2003 |
RENAULT | Megane 1.4 16V | [K4J714] | 03.1999-08.2003 |
RENAULT | Megane 1.4 16V | [K4J730] | 11.2002-02.2008 |
RENAULT | Megane 1.4 16V | [K4J732] | 10.2003-02.2008 |
RENAULT | Megane 1.4 16V | [K4J740] | 11.2002-02.2008 |
RENAULT | Megane 1.4 16V | [K4J750] | 03.1999-07.2003 |
RENAULT | Megane 1.4 16V | [K4J750] | 03.1999-08.2003 |
RENAULT | Megane 1.4 16V Grandtour | [K4J714] | 03.1999-08.2003 |
RENAULT | Megane 1.4 16V Grandtour | [K4J750] | 03.1999-08.2003 |
RENAULT | Megane 1.4 Sport Tourer | [K4J730] | 08.2003-07.2009 |
RENAULT | Megane 1.4 Sport Tourer | [K4J740] | 08.2003-07.2009 |
RENAULT | Megane 1.5 dCi | [K9K722] | 08.2003-02.2008 |
RENAULT | Megane 1.5 dCi | [K9K724] | 05.2005-02.2008 |
RENAULT | Megane 1.5 dCi | [K9K724] | 05.2005-12.2010 |
RENAULT | Megane 1.5 dCi | [K9K728] | 10.2003-02.2008 |
RENAULT | Megane 1.5 dCi | [K9K729] | 10.2003-02.2008 |
RENAULT | Megane 1.5 dCi | [K9K732] | 03.2006-01.2009 |
RENAULT | Megane 1.6 | [K4M760] | 09.2003- |
RENAULT | Megane 1.6 | [K4M760] | 09.2003-03.2009 |
RENAULT | Megane 1.6 | [K4M761] | 09.2003- |
RENAULT | Megane 1.6 | [K4M761] | 09.2003-03.2009 |
RENAULT | Megane 1.6 | [K4M762] | 05.2005- |
RENAULT | Megane 1.6 | [K4M788] | 06.2005-02.2008 |
RENAULT | Megane 1.6 16V | [K4M700] | 03.1999-07.2003 |
RENAULT | Megane 1.6 16V | [K4M700] | 03.1999-08.2002 |
RENAULT | Megane 1.6 16V | [K4M701] | 03.1999-07.2003 |
RENAULT | Megane 1.6 16V | [K4M701] | 03.1999-08.2002 |
RENAULT | Megane 1.6 16V | [K4M706] | 03.1999-07.2003 |
RENAULT | Megane 1.6 16V | [K4M706] | 03.1999-08.2002 |
RENAULT | Megane 1.6 16V | [K4M708] | 03.1999-07.2003 |
RENAULT | Megane 1.6 16V | [K4M708] | 03.1999-08.2002 |
RENAULT | Megane 1.6 16V | [K4M709] | 03.1999-07.2003 |
RENAULT | Megane 1.6 16V | [K4M709] | 03.1999-08.2002 |
RENAULT | Megane 1.6 16V | [K4M760] | 01.2006- |
RENAULT | Megane 1.6 16V | [K4M760] | 01.2006-06.2008 |
RENAULT | Megane 1.6 16V | [K4M760] | 11.2002-02.2008 |
RENAULT | Megane 1.6 16V | [K4M761] | 01.2006- |
RENAULT | Megane 1.6 16V | [K4M761] | 01.2006-06.2008 |
RENAULT | Megane 1.6 16V | [K4M812] | 01.2006- |
RENAULT | Megane 1.6 16V | [K4M812] | 01.2006-06.2008 |
RENAULT | Megane 1.6 16V | [K4M813] | 01.2006- |
RENAULT | Megane 1.6 16V | [K4M813] | 01.2006-06.2008 |
RENAULT | Megane 1.6 16V | [K4M848] | 11.2008- |
RENAULT | Megane 1.6 16V | [K4M858] | 11.2008- |
RENAULT | Megane 1.6 16V | [K4M866] | 11.2008- |
RENAULT | Megane 1.6 16V Bifuel | [K4M866] | 11.2008- |
RENAULT | Megane 1.6 16V Flex-Fuel | [K4M856] | 02.2008- |
RENAULT | Megane 1.6 16V Grandtour | [K4M700] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V Grandtour | [K4M701] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V Grandtour | [K4M708] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V Grandtour | [K4M709] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V Grandtour | [K4M712] | 03.1999-08.2003 |
RENAULT | Megane 1.6 16V Grandtour | [K4M848] | 05.2009- |
RENAULT | Megane 1.6 16V Grandtour | [K4M858] | 05.2009- |
RENAULT | Megane 1.6 16V Grandtour | [K4M866] | 05.2009- |
RENAULT | Megane 1.6 16V Hi-Flex | [K4M858] | 11.2008-08.2015 |
RENAULT | Megane 1.6 16V Hi-Flex | [K4M866] | 11.2008-08.2015 |
RENAULT | Megane 1.6 16V Hi-Flex Sport Tourer | [K4M856] | 02.2008-07.2009 |
RENAULT | Megane 1.6 16V Sport Tourer | [K4M760] | 01.2006-08.2009 |
RENAULT | Megane 1.6 16V Sport Tourer | [K4M761] | 01.2006-08.2009 |
RENAULT | Megane 1.6 16V Sport Tourer | [K4M812] | 01.2006-08.2009 |
RENAULT | Megane 1.6 16V Sport Tourer | [K4M813] | 01.2006-08.2009 |
RENAULT | Megane 1.6 BiFuel Grandtour | [K4M866] | 11.2008- |
RENAULT | Megane 1.6 Flex-Fuel | [K4M788] | 01.2007-02.2008 |
RENAULT | Megane 1.6 Flex-Fuel | [K4M856] | 01.2007- |
RENAULT | Megane 1.6 Sport Tourer | [K4M760] | 08.2003-07.2009 |
RENAULT | Megane 1.6 Sport Tourer | [K4M761] | 08.2003-07.2009 |
RENAULT | Megane CC 1.6 16V | [K4M858] | 06.2010- |
RENAULT | Megane Scenic 1.6 16V | [K4M700] | 04.1998-10.1999 |
RENAULT | Megane Scenic 1.6 16V | [K4M701] | 04.1998-10.1999 |
RENAULT | Megane Scenic 1.6 16V | [K4M704] | 04.1998-10.1999 |
RENAULT | Megane Scenic 1.6 16V | [K4M708] | 04.1998-10.1999 |
RENAULT | Modus 1.4 | [K4J770] | 12.2004- |
RENAULT | Modus 1.4 | [K4J780] | 12.2004- |
RENAULT | Modus 1.5 dCi | [K9K750] | 09.2004- |
RENAULT | Modus 1.5 dCi | [K9K752] | 12.2004- |
RENAULT | Modus 1.5 dCi | [K9K760] | 12.2004- |
RENAULT | Modus 1.5 dCi | [K9K764] | 05.2005- |
RENAULT | Modus 1.5 dCi | [K9K766] | 12.2004- |
RENAULT | Modus 1.5 dCi | [K9K768] | 12.2004- |
RENAULT | Modus 1.5 dCi | [K9K772] | 05.2007- |
RENAULT | Modus 1.5 dCi 75 | [K9K770] | 10.2010- |
RENAULT | Modus 1.5 dCi 90 | [K9K750] | 10.2010- |
RENAULT | Modus 1.5 dCi 90 | [K9K770] | 10.2010- |
RENAULT | Modus 1.6 | [K4M790] | 12.2004- |
RENAULT | Modus 1.6 | [K4M791] | 12.2004- |
RENAULT | Modus 1.6 | [K4M794] | 12.2004- |
RENAULT | Modus 1.6 | [K4M800] | 12.2004- |
RENAULT | Modus 1.6 | [K4M801] | 12.2004- |
RENAULT | Scenic 1.4 | [K4J730] | 06.2003-11.2008 |
RENAULT | Scenic 1.4 | [K4J740] | 06.2003-11.2008 |
RENAULT | Scenic 1.4 | [K4J770] | 06.2003-11.2008 |
RENAULT | Scenic 1.4 16V | [K4J714] | 09.1999-08.2003 |
RENAULT | Scenic 1.4 16V | [K4J750] | 09.1999-08.2003 |
RENAULT | Scenic 1.5 dCi | [K9K728] | 11.2003-08.2005 |
RENAULT | Scenic 1.5 dCi | [K9K729] | 11.2003-08.2005 |
RENAULT | Scenic 1.6 | [K4M700] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M706] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M707] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M761] | 06.2003-10.2006 |
RENAULT | Scenic 1.6 | [K4M776] | 09.1999-09.2003 |
RENAULT | Scenic 1.6 | [K4M782] | 06.2003-10.2006 |
RENAULT | Scenic 1.6 16V | [K4M706] | 10.2005-11.2008 |
RENAULT | Scenic 1.6 16V | [K4M766] | 10.2005-11.2008 |
RENAULT | Scenic 1.6 16V | [K4M812] | 10.2005-11.2008 |
RENAULT | Scenic 1.6 16V | [K4M813] | 10.2005-11.2008 |
RENAULT | Scenic 1.6 16V | [K4M858] | 02.2009- |
RENAULT | Scenic 1.6 16V | [K4MR858] | 02.2009- |
RENAULT | Scenic 1.6 16V Bifuel | [K4M866] | 02.2009- |
RENAULT | Scenic 1.6 16V Bifuel | [K4M866] | 04.2012-12.2013 |
RENAULT | Scenic 1.6 E85 | [K4M866] | 02.2009- |
RENAULT | Thalia 1.4 16V | [K4J712] | 08.2000- |
RENAULT | Twingo 1.2 Turbo | [D4F780] | 03.2007- |
RENAULT | Twingo 1.2 Turbo | [D4F782] | 03.2007- |
RENAULT | Twingo 1.5 dCi | [K9K740] | 03.2007- |
RENAULT | Twingo 1.5 dCi 75 | [K9K820] | 10.2010- |
RENAULT | Twingo 1.5 dCi 90 | [K9K820] | 10.2010- |
RENAULT | Twingo 1.6 RS | [K4M754] | 05.2008- |
RENAULT | Twingo 1.6 RS | [K4M854] | 05.2008- |
RENAULT | Wind 1.6 | [K4M854] | 07.2010- |
Reference Information
7701475896 ALTL286 89212834 ALT173360 A3103 2015336.1 9.44391E+11 7711368719 LRA3155 2605275A TG11C066 442441 575.593.110.004 TG11C069 28-5767 439593 ALT00745 STX100497 0986080710 PRAL286V 8200660033 2015336 AI-90256 8200410681 20179633OE RH-410018 7701476812 ALTL286V CAL15336AS LRA03155 231008578R DRA0292 CA1975IR A12VA0057 ALTL286NE 4697 210477 301975RI ANM32512X Mar-75 EAA-221085 20179633BN CGB-85767 575.593.110.501 575.593.110.500 200133 5515105 DA1402 7711368380 8200390675 STX100497R MRA90544 A12VA0057AS VAL439593 8200772726 CAL15336GS 301975RIV RAA11303 440068 DA1402N 57139 9.4332E+11 TG11C041 ALT173360A PRAL286 63731975010 20453N 114882 8200667614 A12VA0057A2Video/Publications
A3103View your shopping basket or Browse other items in Alternators.
