Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 456.96 including GST
NZ$ 397.36 excluding GST
or four payments of $114.24
with
Learn More
each
A3054
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
SG12B018Associated Numbers
0124515024 0124515027 0124515034 06B903016F 06B903016G 071903016D 071903016E 0986044310 11.1664 11.1664M 113283 13951N 2015251 20179152OE 23244R 2542295 28-3868 28-4719 301664RI 32044310 4035 437176 439263 56921 89212701 8EL737986-001 9044310 9212701 AEC1664 AEK2244 ALT10374 CA1664IR CAL15251GS DRA0135 DRB4310 EAA-221446 LRA01969 LRA02244 SA287 SG12B018Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 169 mm |
| Mount Inside Length or Pad Mount C-C (C) | 83.5 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 34.5 mm |
| Pulley Type | SOLID |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.6 | [AHL] | 01.1999-07.1999 |
| AUDI | A4 1.6 | [ALZ] | 07.2000-09.2001 |
| AUDI | A4 1.6 | [ANA] | 08.1998-07.2000 |
| AUDI | A4 1.6 | [ARM] | 08.1998-07.1999 |
| AUDI | A4 1.8 | [ADR] | 01.1999-04.1999 |
| AUDI | A4 1.8 | [AFY] | 01.1999-09.2001 |
| AUDI | A4 1.8 | [APT] | 04.1999-10.2000 |
| AUDI | A4 1.8 | [ARG] | 08.1998-10.2000 |
| AUDI | A4 1.8 | [AVV] | 06.2000-10.2000 |
| AUDI | A4 1.8 Quattro | [AFY] | 01.1999-09.2001 |
| AUDI | A4 1.8 Quattro | [APT] | 04.1999-09.2001 |
| AUDI | A4 1.8 Quattro | [ARG] | 08.1998-06.2000 |
| AUDI | A4 1.8 Turbo | [AJL] | 01.1999-09.2001 |
| AUDI | A4 1.8 Turbo | [ANB] | 05.1999-06.2000 |
| AUDI | A4 1.8 Turbo | [APU] | 08.1998-07.1999 |
| AUDI | A4 1.8 Turbo | [ARK] | 08.1998-07.1999 |
| AUDI | A4 1.8 Turbo | [AWT] | 06.2000-10.2000 |
| AUDI | A4 1.8 Turbo Quattro | [AJL] | 01.1999-09.2001 |
| AUDI | A4 1.8 Turbo Quattro | [ANB] | 07.1999-06.2000 |
| AUDI | A4 1.8 Turbo Quattro | [APU] | 02.1999-09.2001 |
| AUDI | A4 1.8 Turbo Quattro | [ARK] | 07.1998-07.1999 |
| AUDI | A4 1.8 Turbo Quattro | [AWT] | 06.2000-09.2001 |
| AUDI | A6 1.8 | [AFY] | 07.1998- |
| AUDI | A6 1.8 | [AJP] | 08.1998- |
| AUDI | A6 1.8 | [ANB] | 01.1999-09.2000 |
| AUDI | A6 1.8 | [APU] | 11.1998-04.2001 |
| AUDI | A6 1.8 | [AQE] | 01.1999-04.2001 |
| AUDI | A6 1.8 | [ARH] | 01.1999-04.2001 |
| AUDI | A6 1.8 | [ARK] | 01.1999-05.1999 |
| AUDI | A6 1.8 Turbo | [AEB] | 08.1998-01.1999 |
| AUDI | A6 1.8 Turbo | [AJL] | 08.1998- |
| AUDI | A6 1.8 Turbo | [ANB] | 01.1999-09.2000 |
| AUDI | A6 1.8 Turbo | [APU] | 11.1998-04.2001 |
| AUDI | A6 1.8 Turbo | [ARK] | 01.1999-05.1999 |
| AUDI | A6 1.8 Turbo Quattro | [AEB] | 08.1998-01.1999 |
| AUDI | A6 1.8 Turbo Quattro | [AJL] | 02.1998- |
| AUDI | A6 1.8 Turbo Quattro | [ANB] | 01.1999-09.2000 |
| AUDI | A6 1.8 Turbo Quattro | [APU] | 11.1998-05.2001 |
| AUDI | A6 1.8 Turbo Quattro | [ARK] | 01.1999-05.1999 |
| SKODA | Superb 1.8 Turbo 20V | [AWT] | 12.2001- |
| SKODA | Superb 2.0 | [AZM] | 12.2001- |
| VW | Passat 1.6 | [ADP] | 09.1998-11.2000 |
| VW | Passat 1.6 | [AHL] | 09.1998-11.2000 |
| VW | Passat 1.6 | [ALZ] | 11.2000-05.2005 |
| VW | Passat 1.6 | [ANA] | 07.1999-11.2000 |
| VW | Passat 1.6 | [ARM] | 01.1999-11.2000 |
| VW | Passat 1.8 | [ADR] | 09.1998-01.1999 |
| VW | Passat 1.8 | [APT] | 01.1999-08.2000 |
| VW | Passat 1.8 | [ARG] | 02.1999-11.2000 |
| VW | Passat 1.8 Syncro 4-Motion | [ADR] | 09.1998-11.2000 |
| VW | Passat 1.8 Syncro 4-Motion | [APT] | 01.1999-11.2000 |
| VW | Passat 1.8 Syncro 4-Motion | [ARG] | 01.1999-11.2000 |
| VW | Passat 1.8 Turbo | [AEB] | 09.1998-11.2000 |
| VW | Passat 1.8 Turbo | [ANB] | 08.1998-11.2000 |
| VW | Passat 1.8 Turbo | [APU] | 01.1999-11.2000 |
| VW | Passat 1.8 Turbo | [AWM] | 02.2001-05.2005 |
| VW | Passat 1.8 Turbo 20V | [AWL] | 11.2000-05.2005 |
| VW | Passat 1.8 Turbo 20V | [AWT] | 11.2000-05.2005 |
| VW | Passat 2.0 | [AZM] | 11.2000-05.2005 |
| VW | Passat 2.0 | [BFF] | 11.2000-02.2007 |
| VW | Passat 2.0 4-Motion | [AZM] | 11.2000-05.2005 |
| VW | Passat 2.3 V5 | [AZX] | 11.2000-05.2005 |
| VW | Passat 2.3 V5 4-Motion | [AZX] | 11.2000-05.2005 |
| VW | Passat 2.3 VR5 | [AGZ] | 09.1998-08.2000 |
| VW | Passat 2.3 VR5 | [AZX] | 11.2000-05.2005 |
| VW | Passat 2.3 VR5 4-Motion | [AZX] | 11.2000-05.2005 |
| VW | Passat 2.3 VR5 Syncro 4-Motion | [AGZ] | 09.1998-08.2000 |
Reference Information
301664RI 2015251 28-4719 AEK2244 SA287 038903018FX ALT172510 SG12B018 ALT0066 06B903016GX STX100306R LRA1969 28-3868 23244R ALTS836 437176 DRB4310 A12VA0500A2 0124515024 8EL737986-001 0124515027 89212701 441811 DRA0135 038903018F 32044310 439263 STX100306 38903018F AEC1664 LRA01969 06B903016G 0124515034 06B903016F 4035 11.1664M LRA2244 6B903016G ALT10374 ALT0A60 6B903016F 310970 STX100514 ALT849 A3054 STX100514R STA0401R 0986044310 113283 CGB-83868 ANM32355X 071903016E 9212701 071903016D 20179152OE CAL15251GS 6B903016GX LRA02244 2542295 56921 CA1664IR STX100044 9044310 PRAS836V STX100044R 13951N 210535 11.1664Video/Publications
