Brand new AS-PL Alternator
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 536.67 including GST
NZ$ 466.67 excluding GST
or four payments of $134.17
with
Learn More
each
A2112S
No stock in NZ
No stock in NZ
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
LR190-770 UD20718A 113787 CAL20243GS DRA0911 28-5961 LR190770F LR190770B LR190770C ALH9560 554898RIH LRA03349 23100VC40C 23100VS40B 23100VS40C 165.933.090 20145342OE 2020243.1 HITLR190-770Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81 mm |
| OEM Product | No |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 7 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 38 mm |
| Pulley Type | CLUTCH |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | CLS 500 3.0 | [M278.922] | 01.2012- |
| NISSAN | Patrol 3.0 DTi | [ZD30DDTi] | 01.2000- |
| NISSAN | Patrol 3.0 DTi | [ZD30DDTi] | 01.2004- |
Reference Information
STX100070 STX100070R LR190-770 LRA03349 ALT222430 UD20718A 446940 23100VS40B LRA3349 23100VS40D 23100VS40C 554898RIH PRAE740 CAL20243GS 28-5961 23100-VS40A DRA0911 ALH9560 136127 165.933.090 23100VC40C 2506127 LR190770C LR190770B 20145342OE ALTE740 LR190-770E LR190770E HITLR190-770 2020243.1 LR190770FVideo/Publications
A2112SRelated Items
