Associated Numbers
021903016A 021903016AV 021903016AX 136145 2506145 90-25-1223 95560311600 A-80580 AEG1380 ALH2903 DA2847 DRA1737 HITLR1190-919 LR1190-919Specifications
Amp | 190 A |
Bottom Mounting Foot Width (B) | 14 mm |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Length (L.1) | 206 mm |
Mount Inside Length or Pad Mount C-C (C) | 60.5 mm |
OEM Product | No |
Plug Code | PL_2303 |
Product Line | Premium Line |
Product Type | Remanufactured |
Pulley Grooves | 7 qty |
Pulley Outside Diameter (O.D.1) | 56 mm |
Pulley to Mount Distance (A) | 30.5 mm |
Pulley Type | CLUTCH |
Unit Type | HITACHI |
Voltage | 12 V |
Water Cooled | Yes |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VW | Phaeton 3.2 V6 | [AYT] | 01.2002- |
VW | Phaeton 3.2 V6 | [BKL] | 01.2002- |
VW | Phaeton 3.2 V6 4-Motion | [BKL] | 01.2004- |
VW | Phaeton 3.2 V6 4-Motion | [BRK] | 01.2004- |
VW | Phaeton 3.2 V6 4-Motion | [CHNA] | 01.2008- |
VW | Phaeton 3.2 V6 4-Motion | [CMVA] | 01.2008- |
VW | Touareg 3.2 V6 | [AZZ] | 01.2002-12.2006 |
VW | Touareg 3.2 V6 | [BAA] | 01.2002-12.2006 |
VW | Touareg 3.2 V6 | [BKJ] | 01.2002-12.2006 |
VW | Touareg 3.2 V6 | [BMV] | 01.2002-12.2006 |
VW | Touareg 3.2 V6 | [BMV] | 01.2004-12.2006 |
VW | Touareg 3.2 V6 | [BMX] | 01.2002-12.2006 |
VW | Touareg 3.2 V6 | [BRJ] | 01.2002-12.2006 |
VW | Touareg 3.6 V6 FSi | [BHK] | 01.2005-12.2010 |
VW | Touareg 3.6 V6 FSi | [BHL] | 01.2005-12.2010 |
Reference Information
LR1190940 LR1190956B A-80580 ALT222370A 90-25-1223 ALT222370 AEG1380 PRAJ078 95560311600 059903016TX 2020237.1 059903018L 136145 021903016AX 021903016AV 20145732OE 059903016T 059903019HX LR1190956 HITLR1190-919 2020237 2506145 DA2847 LR1190-919 ALH2903 20145732BN 021903016A CAL20237AS ALTJ078 CAL20237GS 059903019H DRA1737Video/Publications
