Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 602.99 including GST
NZ$ 524.34 excluding GST
or four payments of $150.75
with
Learn More
each
A0531S
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0125711028Associated Numbers
0009060122 0009063322 0125711028 0125711054 0986082150 115759 2010451 209033 24400N 24400N-OE 28-6791 4239 554301RI 554301RIB 555.515.150 57604 89215633 A0009060122 A0009063322 A00090633220080 AEK3651 ALB2571 BOS0125711028 BOS0125711054 CAL10451 CAL10451AS CAL10451ES CAL10451GS CAL10451OS CAL10451RS DRA1065 EAA-223199 EAA-223207 LRA03651 UD13160ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 14.5 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Length (L.1) | 176 mm |
| Mount Inside Length or Pad Mount C-C (C) | 52 mm |
| OEM Product | No |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 32 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| INFINITI | Q30 2.2 D | [651.930] | 11.2015- |
| INFINITI | Q30 2.2 D AWD | [651.930] | 11.2015- |
| MERCEDES BENZ | A 180 1.8 CDi | (W176)[OM651.901] | 06.2012- |
| MERCEDES BENZ | A 200 1.8 CDi | (W176)[OM651.901] | 06.2012- |
| MERCEDES BENZ | A 200 2.1 CDi | (W176)[OM651.930] | 02.2014- |
| MERCEDES BENZ | A 220 2.1 CDi | (W176)[OM651.930] | 01.2014- |
| MERCEDES BENZ | A 220 2.1 CDi | (W176)[OM651.930] | 09.2012- |
| MERCEDES BENZ | A 220 2.2 D | (W176)[OM651.930] | 07.2015- |
| MERCEDES BENZ | A 220 2.2 D 4-Matic | (W176)[OM651.930] | 07.2015- |
| MERCEDES BENZ | B 180 1.8 CDi | (W246)[OM651.901] | 11.2011- |
| MERCEDES BENZ | B 200 1.8 CDi | (W246)[OM651.901] | 11.2011- |
| MERCEDES BENZ | B 200 2.2 CDi | (W242)[OM651.930] | 08.2014- |
| MERCEDES BENZ | B 200 2.2 CDi | (W246)[OM651.930] | 08.2014- |
| MERCEDES BENZ | B 200 2.2 CDi 4-Matic | (W242)[OM651.930] | 08.2014- |
| MERCEDES BENZ | B 200 2.2 CDi 4-Matic | (W246)[OM651.930] | 08.2014- |
| MERCEDES BENZ | B 220 2.1 CDi | (W246)[OM651.930] | 06.2013- |
| MERCEDES BENZ | B 220 2.1 CDi | (W246)[OM651.930] | 11.2011- |
| MERCEDES BENZ | B 220 2.2 CDi | (W242)[OM651.930] | 09.2014- |
| MERCEDES BENZ | B 220 2.2 CDi | (W246)[OM651.930] | 09.2014- |
| MERCEDES BENZ | B 220 2.2 CDi 4-Matic | (W242)[OM651.930] | 09.2014- |
| MERCEDES BENZ | B 220 2.2 CDi 4-Matic | W242)[OM651.930] | 09.2014- |
| MERCEDES BENZ | B 220 2.2 CDi 4-Matic | (W246)[OM651.930] | 09.2014- |
| MERCEDES BENZ | CLA 200 1.8 CDi | (C117)[OM651.901] | 06.2013- |
| MERCEDES BENZ | CLA 200 2.2 CDi | (C117)[OM651.930] | 07.2014- |
| MERCEDES BENZ | CLA 200 2.2 CDi | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | CLA 200 2.2 CDi 4-Matic | (C117)[OM651.930] | 07.2014- |
| MERCEDES BENZ | CLA 200 2.2 CDi 4-Matic | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | CLA 200 2.2 CDi Shooting Brake | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | CLA 220 2.1 CDi | (C117)[OM651.930] | 01.2013- |
| MERCEDES BENZ | CLA 220 2.2 CDi | (C117)[OM651.930] | 09.2014- |
| MERCEDES BENZ | CLA 220 2.2 CDi | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | CLA 220 2.2 CDi 4-Matic | (C117)[OM651.930] | 07.2014- |
| MERCEDES BENZ | CLA 220 2.2 CDi 4-Matic | (C117)[OM651.930] | 08.2014- |
| MERCEDES BENZ | CLA 220 2.2 CDi 4-Matic | (C117)[OM651.930] | 09.2014- |
| MERCEDES BENZ | CLA 220 2.2 CDi 4-Matic | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | CLA 220 2.2 CDi 4-Matic | (X117)[OM651.930] | 09.2015- |
| MERCEDES BENZ | CLA 220 2.2 CDi Shooting Brake | (X117)[OM651.930] | 01.2015- |
| MERCEDES BENZ | GLA 200 2.1 CDi | (X156)[OM651.930] | 12.2013- |
| MERCEDES BENZ | GLA 200 2.1 CDi 4-Matic | (X156)[OM651.930] | 12.2013- |
| MERCEDES BENZ | GLA 220 2.1 CDi | (X156)[OM651.930] | 12.2013- |
| MERCEDES BENZ | GLA 220 2.1 CDi 4 Matic | (X156)[OM651.930] | 12.2013- |
| MERCEDES BENZ | GLA 220 2.1 CDi 4-Matic | (X156)[OM651.930] | 12.2013- |
| MERCEDES BENZ | GLA 220 2.2 D | (X156)[OM651.930] | 07.2015- |
| MERCEDES BENZ | GLA 220 2.2 D 4-Matic | (X156)[OM651.930] | 07.2015- |
Reference Information
20010451AV 9090797 ALT124510A A12BH0553AS UD13160A AEK3651 ALB2571 STX110063R 115759 CGB-86791 PRAL374 10443995 WG2277505 555.515.150.010 443409 24400N 00090633220080 AZMT-49-035-2036 0125711028 A12BH0553A2 AL03267 3120674 20101154OE 32082150 3120675 3120676 8EL011713-521 IR7470 20101154BN 555.515.150.280 CAL10451AS ABO451A ME8110 2253111502 0986082150 00090601220080 8550505697 BF0427770160 604ST75 A00090633220080 A0531S LRA3651 444286 555.515.150.346 BOS0125711028 A0009060122 ALTL374RR A0009063322 2010451.0 DRA1065 20010451OV 2010451.1 A12BH0553 28-6791 554301RIB 57604 12090489 0009060122 0009063322 89215633 209033 ALTL374 BOS0125711054 555.515.150.211 LRA03651 ALT10005 555.515.150.014 0125711028-R WG2196856 CGB-11028 AC-CBA5836 CAL10451GS ALT124510 H5510484 442522 ABO451 5510484G QRA3416 5510484 A00090601220080 24400N-OE 0125711054 4239 H5510484G 554301RIVideo/Publications
A0531SView your shopping basket or Browse other items in Alternators.
