Remanufactured AS-PL Alternator
PREMIUM LINE
AS-PL
BOSCH
Price:
NZ$ 402.65 including GST
NZ$ 350.13 excluding GST
or four payments of $100.66
with
Learn More
each
A0417PR
No stock in NZ
No stock in NZ
Associated Numbers
0124325122 0124525064 063533251220 063731913010 063731915010 0986049950 114705 115490 2010320 210940 23835N 28-5673 301913RIB 301915RI 301915RIB 4763 504057813 504087183 505.546.140 89212810 8EL738211-731 AEK3060 AG1063 ALT10614 BOS0124525064 CA1913IR CAL10320 CAL10320AS CAL10320ES CAL10320GS CAL10320OS CAL10320RS DRA0039 EAA-221424 LRA03061 LRA3061 MQA1913 MQA1915 RAA11140Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 81 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 38 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | Jumper 3.0 HDi | [F1CE0481D(F30DT)] | 09.2006- |
| CITROEN | Jumper 3.0 HDi | [F1CE0481D(FG30DT)] | 07.2010- |
| CITROEN | Jumper 3.0 HDi | [F1CE0481D(FG30DT)] | 09.2006- |
| CITROEN | Jumper 3.0 HDi 145 | [F1CE348IN] | 07.2010- |
| CITROEN | Jumper 3.0 HDi 155 | [F1CE0481D(F30DT)] | 07.2010- |
| CITROEN | Jumper 3.0 HDi 180 | [F1CE3481E] | 07.2011- |
| FIAT | Ducato 3.0 140 Natural Power M90 | [F1CE0441A] | 04.2009- |
| FIAT | Ducato 3.0 D 140 Natural Power | [F1CE0441A] | 04.2009- |
| FIAT | Ducato 3.0 JTD 160 Multijet Power | [F1CE0481D] | 07.2006- |
| FIAT | Ducato 3.0 JTD Multijet Power | [F1CE0481D] | 07.2006- |
| FIAT | Ducato 3.0 JTD Multijet Power | [F1CE3481M] | 07.2006- |
| FIAT | Ducato 3.0 Multijet 150 | [F1CE3481N] | 04.2010- |
| FIAT | Ducato 3.0 Multijet 160 | [F1CE3481M] | 07.2006- |
| FIAT | Ducato 3.0 Multijet 4x4 | [F1CE0481D] | 07.2006- |
| FIAT | Ducato 3.0 Multijet 4x4 | [F1CE3481M] | 07.2006- |
| FIAT | Ducato 3.0 Natural Power | [F1CE0441A] | 04.2009- |
| IVECO | 35 C 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 35 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 35 C 14 3.0 D | [F1CE0481A] | 09.2004-04.2006 |
| IVECO | 35 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 35 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 35 C 17 3.0 D | [F1CE0481B] | 01.2005-04.2006 |
| IVECO | 35 C 18 3.0 D | [F1CE0481HA] | 05.2006- |
| IVECO | 35 S 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 35 S 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 35 S 14 3.0 D | [F1CE0481A] | 01.2004-05.2006 |
| IVECO | 35 S 14G 3.0 | [F1CE0441A] | 07.2009- |
| IVECO | 35 S 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 35 S 17 3.0 D | [F1CE0481B] | 01.2005-04.2006 |
| IVECO | 35 S 18 3.0 D | [F1CE0481HA] | 05.2006- |
| IVECO | 35 S 18W 3.0 | [F1CE0481HC] | 06.2006-08.2011 |
| IVECO | 40 C 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 40 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 40 C 14 3.0 D | [F1CE0481A] | 09.2004-04.2006 |
| IVECO | 40 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 40 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 40 C 17 3.0 D | [F1CE0481B] | 01.2004-05.2006 |
| IVECO | 40 C 17 3.0 D | [F1CE0481B] | 01.2005-04.2006 |
| IVECO | 40 C 18 3.0 D | [F1CE0481HA] | 05.2006- |
| IVECO | 40 S 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 40 S 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 40 S 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 40 S 17 3.0 D | [F1CE0481B] | 01.2005-04.2006 |
| IVECO | 45 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 45 C 18 3.0 D | [F1CE0481HA] | 05.2006- |
| IVECO | 50 C 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 50 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 50 C 14 3.0 D | [F1CE0481A] | 09.2004-04.2006 |
| IVECO | 50 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 50 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 50 C 17 3.0 D | [F1CE0481B] | 09.2004-04.2006 |
| IVECO | 50 C 18 3.0 D | [F1CE0481HA] | 05.2006- |
| IVECO | 55 S 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 55 S 18W 3.0 | [F1CE0481HC] | 06.2006-08.2011 |
| IVECO | 60 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 60 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 60 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 60 C 18 3.0 D | [F1CE0481HC] | 05.2006- |
| IVECO | 65 C 14 3.0 | [F1CCNG] | 07.2009- |
| IVECO | 65 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 65 C 14 3.0 D | [F1CE0481A] | 09.2004-04.2006 |
| IVECO | 65 C 15 3.0 D | [F1CE0481FA] | 05.2006- |
| IVECO | 65 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | 65 C 17 3.0 D | [F1CE0481B] | 09.2004-04.2006 |
| IVECO | 65 C 18 3.0 D | [F1CE0481HC] | 05.2006- |
| IVECO | 70 C 14 3.0 | [F1CE3481LC] | 07.2009- |
| IVECO | 70 C 17 3.0 | [F1CE0481HA] | 07.2009- |
| IVECO | Daily V 2.3 | [F1AE3481B] | 09.2011- |
| IVECO | Daily V 3.0 | [F1CE3481C] | 09.2011- |
| IVECO | Daily V 3.0 | [F1CE3481J] | 09.2011- |
| IVECO | Daily V 3.0 | [F1CE3481K] | 09.2011- |
| IVECO | Daily V 3.0 | [F1CE3481L] | 09.2011- |
| IVECO | Massif 3.0 HPi | [F1CE0481FA] | 10.2008- |
| IVECO | Massif 3.0 HPi Single Cab | [F1CE0481FA] | 10.2008- |
| IVECO | Massif 3.0 HPT | [F1CE0481HA] | 10.2008- |
| IVECO | Massif 3.0 HPT Single Cab | [F1CE0481HA] | 10.2008- |
| PEUGEOT | Boxer 3.0 HDi | [F1CE3481E] | 03.2011- |
| PEUGEOT | Boxer 3.0 HDi | [F30DTE5] | 04.2010- |
| PEUGEOT | Jumpy 2.0 HDi 165 | [RHH(DW10CTED4)] | 07.2010- |
Reference Information
114705 STX102030 0124325122 063731915010 23835N 442398 AEK3060 A12BH0267AS 504057813 ALT1311 4763 CAL10320 2010320 0124525064 210940 301913RIB CAL10320ES PRAS262 LRA3061 CAL10320AS 504204173 AG1063 504087183 ALTS262 ALT123200 A12BH0267 A12BH0266A2 505.546.140 BOS0124525064 STX100341 STX100341R 301913RI 063731913010 89212810 MQA1913 209024 5705KL MQA1915 442460 063533251220 LRA03061 RAA11140 ALTL476B ALT10614 CAL10320RS 301915RIB CAL10320GS 1613272380 AI-90032 8EL738211-731 DRA0039 CGB-85673 CA1913IR 0986049950 A12BH0267A2 311118 CAL10320OS STX100087 115490 28-5673 301915RI ALTL736Video/Publications
