Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 471.58 including GST
NZ$ 410.07 excluding GST
or four payments of $117.90
with
Learn More
each
A0154
No stock in NZ
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
0124515031Associated Numbers
0124515004 0124515031 0986042800 11.1821 28-4777 28-4863 301765RI 301821RI 32046150 437611 57065 6204095 89213707 8EL738206-001 9042800 9195336 AEC1765 AEC1821 ALT10054 CA1821IR DRB2800 DRB6150 EAA-221369 LRA02295 LRA02359 SA817Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 34 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | 11 mm |
| Length (L.1) | 178 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 54.5 mm |
| Pulley Type | NO PULLEY |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra G 1.4 i 16V | [X14XE] | 09.1997-09.2000 |
| OPEL | Astra G 1.4 i 16V | [X14XE][Z14XE] | 09.2000-01.2004 |
| OPEL | Astra G 1.6 | [Z16YNG] | 09.2002-06.2004 |
| OPEL | Astra G 1.6 16V | [X16XEL] | 09.1997-08.2000 |
| OPEL | Astra G 1.6 i | [X16SZR] | 02.1998-09.2000 |
| OPEL | Astra G 1.6 i | [X16SZR][Z16SE] | 09.2000-01.2004 |
| OPEL | Astra G 1.6 i 16V | [X16XEL] | 09.1997-08.2000 |
| OPEL | Astra G 1.6 i 16V | [X16XEL][Z16XE] | 09.1998-01.2005 |
| OPEL | Astra G 1.8 16V | [X18XE1] | 09.1997-08.2000 |
| OPEL | Astra G 1.8 i 16V | [X18XE1] | 09.1997-08.2000 |
| OPEL | Astra G 1.8 i 16V | [X18XE1][Z18XE] | 09.2000-02.2005 |
| OPEL | Astra G 2.0 | [Z20LER] | 11.2002- |
| OPEL | Astra G 2.0 16V | [X20XEV] | 09.1997-06.2004 |
| OPEL | Astra G 2.0 i 16V | [X20XER] | 11.1999-09.2002 |
| OPEL | Astra G 2.0 i 16V | [X20XEV] | 09.1997-01.2004 |
| OPEL | Astra G 2.0 OPC | [Z20LET] | 09.2001-06.2004 |
| OPEL | Combo 1.6 16V Tour | [Z16YNG] | 06.2006- |
| OPEL | Corsa C 1.4 i 16V | [Z14XE] | 09.2000- |
| OPEL | Corsa C 1.8 i 16V | [Z18XE] | 09.2000- |
| OPEL | Signum 1.8 | [Z18XE] | 05.2003- |
| OPEL | Vectra C 1.8 | [Z18XEL] | 04.2002-08.2005 |
| OPEL | Vectra C 1.8 i | [Z18XE] | 10.2003- |
| OPEL | Vectra C 1.8 i 16V | [Z18XE] | 04.2002- |
| OPEL | Vectra C 1.8 i 16V | [Z18XEL] | 04.2002- |
| OPEL | Vectra C 1.8 i 16V GTS | [Z18XE] | 08.2002- |
| OPEL | Vectra C 1.8 i 16V GTS | [Z18XEL] | 08.2002- |
| OPEL | Zafira 1.6 | [Z16YNG] | 01.2006- |
| OPEL | Zafira A 1.6 16V | [X16XEL] | 04.1999-07.2005 |
| OPEL | Zafira A 1.6 16V | [X16XEL][Z16XE] | 09.2000-07.2005 |
| OPEL | Zafira A 1.6 i | [Z16YNG] | 09.2001- |
| OPEL | Zafira A 1.8 16V | [X18XE1] | 04.1999-09.2000 |
| OPEL | Zafira A 1.8 16V | [X18XE1][Z18XE] | 09.2000-07.2005 |
| OPEL | Zafira A 2.0 | [Z20LET] | 09.2001-06.2005 |
| OPEL | Zafira A 2.0 OPC | [Z20LET] | 11.2002-07.2005 |
| VAUXHALL | Astra G 1.4 16V | [X14XE] | 09.1997-08.2000 |
| VAUXHALL | Astra G 1.4 16V | [Z14XE] | 09.2000-08.2005 |
| VAUXHALL | Astra G 1.6 | [X16SZR] | 09.1997-08.2005 |
| VAUXHALL | Astra G 1.6 16V | [X16XEL] | 09.1997-08.2000 |
| VAUXHALL | Astra G 1.6 16V | [Z16XE] | 09.2000-08.2005 |
| VAUXHALL | Astra G 1.8 16V | [X18XE1] | 09.1997-08.2000 |
| VAUXHALL | Astra G 2.0 16V | [X20XEV] | 09.1997-08.2005 |
| VAUXHALL | Astra MK IV 1.6 16V | [Z16XE] | 09.2000- |
| VAUXHALL | Astra MK IV 1.8 16V | [Z18XE] | 09.2000- |
| VAUXHALL | Astra MK IV 1.8 16V | [Z18XE] | 09.2000-08.2005 |
| VAUXHALL | Astra MK IV 1.8 Dualfuel 16V | [Z18XE] | 09.2002-08.2005 |
| VAUXHALL | Astra MK IV 2.0 Turbo 16V | [Z20LET] | 09.2000-08.2005 |
| VAUXHALL | Astravan MK IV 1.6 i | [X16SZR] | 08.1998-09.2000 |
| VAUXHALL | Astravan MK IV 1.6 i | [Z16SE] | 09.2000- |
| VAUXHALL | Corsa MK II 1.4 16V | [Z14XE] | 09.2000-08.2003 |
| VAUXHALL | Vectra Mk II 1.6 16V | [Z16XE] | 06.2004- |
| VAUXHALL | Vectra Mk II 1.8 | [Z18XER] | 04.2002- |
| VAUXHALL | Vectra Mk II 1.8 16V | [Z18XE] | 10.2003- |
| VAUXHALL | Vectra Mk II 1.8 i 16V | [Z18XE] | 04.2002- |
| VAUXHALL | Vectra Mk II 1.8 i 16V GTS | [Z18XE] | 08.2002-08.2005 |
| VAUXHALL | Zafira 1.6 16V | [X16XEL] | 04.1998- |
| VAUXHALL | Zafira 1.8 16V | [X18XE1] | 04.1998- |
| VAUXHALL | Zafira 1.8 16V | [Z18XE] | 09.2000-06.2005 |
Reference Information
CA1821IR CGB-12800 CGB-84777 13156050 LRA02359 13156054 57065 13125229 32046150 UA CA1765IR 6204178 311056 6204095 6204172 93175808 437611 210584 ALT123330 PRAS603 93180414 9173572 LRA2295 301821RI 90561972 93175957 301765RI 9195336 AEC1821 0124515031 115619 ALT10054 441968 R1530025 89213707 93117508 6204158 9512794 LRA02295 STX101604 LRA2359 28-4777 8EL738206-001 ALT123330A DRB6150 93175989 STX100166R 0986042800 SA817 WX 9042800 ALTS603 28-4863 13147093 9117936 DRB2800 ANM48370X ALT1420 6204080 STX100166 11.1821 93177834 AEC1765 ALT123140Video/Publications
