- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
AEA2210 AUTOELECTRO
0986040471 BOSCH
0986042331 BOSCH
111579 CARGO
CAL40110AS CASCO
9279 CEVAM
DRA3503 DELCO
1012110060 DENSOList
1012110061 DENSOList
1012110062 DENSOList
1012110120 DENSOList
1012110181 DENSOList
1012114580 DENSOList
1012115020 DENSOList
1012115240 DENSOList
EAA221444 EAA
56617 EAI
281821 ELSTOCK
9051286 FRIESEN
JA976IR HC PARTS
8EL732741001 HELLA
40976RI KUHNER
11.0976 LAUBER
11.0976M LAUBER
LRB00210 LUCAS
9213467 POWERMAX
20110210 PRESTOLITE
20132011BN REAL
2040110 SANDO
SA394 SOVEREIGN
2706015080 TOYOTAList
2706015090 TOYOTAList
2706015100 TOYOTAList
2706015120 TOYOTA
2706015130 TOYOTA
2706015140 TOYOTAList
437514 VALEO
13482N WAI / TRANSPO
ALT30304 WOODAUTO
0986040471 Bosch ruil
0986042331 Bosch ruil
0986043331 Bosch ruil
1002110060 Denso
1002115020 Denso
1002118991 Denso
1012110060 Denso
1012110061 Denso
1012110062 Denso
1012110080 Denso
1012110120 Denso
1012110180 Denso
1012110181 Denso
1012115020 Denso
1012115080 Denso
1012115240 Denso
1012119500 Denso
1022111110 Denso
111579 Cargo
12060400 EuroTec
12060401 EuroTec
13380R6G WAI
13482 Lester
13482N WAI
13551 Lester
195524070 PSH
20110210 Prestolite
2706002040 Toyota
2706002050 Toyota
2706015080 Toyota
2706015090 Toyota
2706015100 Toyota
2706015120 Toyota
2706015130 Toyota
2706015140 Toyota
2706016390 Toyota
281821 Elstock
437514 Valeo
5466SP Spidan
56617 EAI
56720 EAI
90295209 Wilson
90295233 Wilson
90295236 Wilson
9051286F Friesen
9120690458 Bosch
9120690504 Bosch
ALT1025sa Electrolog
ALT1087sa Electrolog
ALT5041 Unipoint
ALT6087sa Electrolog
ALT6425SA Electrolog
ATA415 ATK
ATA515 ATK
ATA537 ATK
DAN1047 Denso
DRA3503 Remy
F042302025 Bosch
F042A02025 Bosch
HJA976IR HC
JA976IR HC
L39460 ATL
L40470 ATL
L41160 ATL
L42330 ATL
LRB210 Lucas
N5112128 Nipparts
N5112129 Nipparts
R120690504
TRA042 TWA
0123325002 Bosch
0123325012 Bosch
0123325014 Bosch
0986039460 Bosch ruil
0986039461 Bosch ruil
0986041160 Bosch ruil
0986041161 Bosch ruil
1012119280 Denso
12060401 EuroTec
195524080 PSH
20110410 Prestolite
21410 Lester
21410R WAI
2205250 PIC
270600006 Toyota
2706002060 Toyota
2706002061
2706002070
2706002100 Toyota
2706016370
2706016460
282605 Elstock
437517 Valeo
437519 Valeo
5477SP Spidan
56720 EAI
9041160F Friesen
9123325002 Bosch
941160 EDR
ALT1025sa Electrolog
ALT6289sa Electrolog
ATA587 ATK
ATA911 ATK
DRA9460 Remy
DRB1160 Remy
HJA987IR HC
JA987IR HC
LRB00410 Lucas
TRA182 TWA
W27309 van Heck
1022111200 Denso
12060400 EuroTec
195526080 PSH
22613 Lester
2706016430 Toyota
285615 Elstock
290344E PIC
LRA03002 Lucas
Bosch AL3254N
Denso 2100101
References:
Arrowhead AND0036
Bosch AL3254N, AL3254X
Delco 10463613
Denso 1012110060, 1012110120, 2100100
Lester 13482
PIC Picture ID 290365
Wilson 90295236
J&N 40052330
Delco 94854169
Denso 1012110120, 1012110121
General Motors 94854169
Lester 13482
Toyota 2706002050, 2706015100
Bosch AL3254N, AL3254X, AL3264X
Delco 10463613, 10464199, 19134169, 19134214, 3211076, 94853222, 94854169, 94854172, 94854195
Denso 1002118990, 1002118991, 1012110060, 1012110120, 1012115020, 1012115080, 1012115240, 2100100, 2100101, 2100315, 2100316, 2100450, 9761211006, 9761211508, 9761211524
Lester 13481, 13482, 13550, 13551
PIC Picture ID 290357, 290365, 290366, 290366A, 290367
Toyota 2706015090, 2706015140
dxa470 658326 anj013
Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 27.5 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Length (L.1) | 156 mm |
| Mount Inside Length or Pad Mount C-C (C) | 44.5 mm |
| OEM Product | No |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 52 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Carina E 1.6 | (AT190)[4A-FE] | 02.1992-09.1997 |
| TOYOTA | Carina E 1.6 16V | (AT190)[4A-FE] | 08.1993-09.1997 |
| TOYOTA | Carina E 1.6 16V | (CT190)[4A-FE] | 12.1992-09.1997 |
| TOYOTA | Carina E 1.6 GLi | (AT190)[4A-FE] | 02.1992-09.1997 |
| TOYOTA | Carina E 1.6 GLi | (ST191)[4A-FE] | 01.1993-09.1997 |
| TOYOTA | Carina E 1.6 i | (AT190)[4A-FE] | 02.1995-09.1997 |
| TOYOTA | Carina E 1.8 | (AT191)[7A-FE] | 01.1995-09.1997 |
| TOYOTA | Carina E 1.8 i | (AT191)[7A-FE] | 02.1995-07.1997 |
| TOYOTA | Celica 1.8 i 16V | [7A-FE] | 11.1993-11.1999 |
| TOYOTA | Corolla 1.6 | [4A-FE] | 04.1997-10.1999 |
| TOYOTA | Corolla 1.6 GLi | (AE101)[4A-FE] | 05.1992-04.1997 |
| TOYOTA | Corolla 1.6 Si | (AE101)[4A-FE] | 05.1992-04.1997 |
| TOYOTA | Corolla 1.6 Si | (E10)[4A-FE] | 05.1992-04.1997 |
| TOYOTA | Corolla 1.8 4WD | [7A-FE] | 04.1997-07.2001 |
Reference Information
STX110214 27060-15100 27060-15080-84 ANM35723X 27060-15140 13482N 101211-5240 LRB210 A12DE0483A2 2.70602E+11 2T515 002-T537 101211-0061 101211-0062 ALTS915 STX100650 DRA3503 101211-0060 101211-0181 210266 ALT6087 56617 JA976IR STX110214R 9279 AEA2210 27060-15110 437514 101211-4580 LRB00210 27060-15150 CGB-13503 8EL732741-001 SA394 CAL40110AS ALT515 A6012 EAA-221444 27060-02050 20132011BN 27060-15080 11.0976M 111579 100211-5080 27060-15120 9213467 2040110 27060-16450 101211-5020 ALT6706 195.524.070.265 446025 2T537 101211-0120 ALT30304 ALT6425 STX100159 28-1821 27060-02040 002-T515 0986040471 0986042331 27060-15090 2706002050 195.524.070.415 27060-15130 2706016390 195.524.070.058 195.524.070.059 9051286 ALT537 PRAS915 20110210 ALT5900 195.524.070.050 STX100650R 40976RI 27060-16390 11.0976 2706002040Video/Publications
A6012Related Items
