A6358 - Brand new AS-PL Alternator

Associated Numbers

UD12245A ASPL
AEB0551 AUTOELECTRO
110966 CARGO
111048 CARGO
CAL40104 CASCO
2335 CEVAM
2706087201000 DAIHATSUList
2706087202000 DAIHATSUList
2706087501000 DAIHATSUList
2706087502000 DAIHATSUList
2706087801000 DAIHATSU
93027 DELCO
1002111610 DENSOList
1002111611 DENSOList
1002111630 DENSOList
1002111632 DENSOList
1002111640 DENSOList
1002111650 DENSOList
1002111670 DENSOList
1002111680 DENSOList
1002114440 DENSOList
1002114450 DENSOList
1002114490 DENSOList
1002114520 DENSOList
1002114528 DENSOList
1002114560 DENSOList
1002114640 DENSOList
1002114650 DENSOList
1002114660 DENSO
1002114670 DENSO
1002114680 DENSOList
1002114690 DENSO
1002114740 DENSOList
1012111040 DENSO
1012111180 DENSOList
1012111181 DENSO
1012111230 DENSO
1012111320 DENSO
1012112480 DENSO
1022114640 DENSO
14693106 DIXIE
A8855 DIXIE
EAA221653 EAA
EAA221983 EAA
282670 ELSTOCK
JA551IR HC PARTS
6008212350 KOMATSU
1588164200 KUBOTAList
1588164201 KUBOTA
1588164202 KUBOTA
1623124011 KUBOTAList
1623164011 KUBOTAList
1623164012 KUBOTA
1624164010 KUBOTAList
1624164011 KUBOTAList
1624164012 KUBOTAList
1670564011 KUBOTAList
1670564012 KUBOTA
1679164011 KUBOTA
3407075600 KUBOTA
3407075601 KUBOTAList
3407075602 KUBOTAList
3A01174012 KUBOTA
6643664011 KUBOTAList
LRA01560 LUCAS
185046220 PERKINS
89213359 POWERMAX
20140103 PRESTOLITE
115.506.040 PSH
695.509.040 PSH
2040104 SANDO
436497 VALEOList
12198N WAI / TRANSPO
12198R WAI / TRANSPO
702912198 WILSON
90295492 WILSON
ALT30423 WOODAUTO
021670 Andre Niermann
1002111670 Denso
1002114640 Denso
1002114670 Denso
113921 Cargo
115506040 PSH
12060023 EuroTec
12060643 EuroTec
12179 EAI
12179N WAI
12179R WAI
12198N WAI
1247601ND WAI
1649564011 Kubota
1670564011 Kubota
1670564012 Kubota
240936 Cargo
2706087201000 Daihatsu
2706087202000 Daihatsu
2706087210 Toyota
2706087501000 Daihatsu
28100087723 Toyota
282670 Elstock
290199A PIC
5337SP Spidan
90295180 Wilson
93022 EDR
HJA551IR HC
JA551IR HC
1002111671 Denso
1002114650 Denso
1012111481 Denso
12199 EAI
12199N WAI
1247801ND WAI
1623124011 Kubota
1623164013 Kubota
1624164013 Kubota
1679164011 Kubota
282670 Elstock
290193 PIC
3407075600 Kubota
3407075601 Kubota
3407075602 Kubota
6643664011 Kubota
695509040 PSH
90295492N Wilson
9760218465 Denso
DAN2019 Denso
LRA01560 Lucas
1002114520 Denso
1002114521 Denso
12060023 EuroTec
12190 EAI
12190N WAI
12190R WAI
1233601ND WAI
1623164010 Kubota
1623164011 Kubota
1623164012 Kubota
290199 PIC
695511040 PSH
90295340 Wilson
90295340N Wilson
dxa4040 dxa474 dxa487 dxa4106 658359 658361 ANJ313
Denso 100211161

Substitutes:
Delco 93019
Wilson 90295313

References:
Denso 100211161
Lester 23271
J&N 40052028
Denso 9760218163

References:
Denso 1002111610, 1002111630, 1002111640, 1002114690, 1012112480, 9760211163, 9760218163
Kubota 1588164200, 1588164201, 1588164202
PIC Picture ID 290198
Thermo King 5D36221G01, P274934
Arrowhead AND0003
JANNCO 40052028R
Case SBA185046220
Delco 93019
Denso 1002111630, 100211469, 1002114690, 9760211163, 9760218163
Kubota 1588164200, 1588164201
Lester 12189
PIC Picture ID 290198
Thermo King 5D36221G01
Wilson 702912189, 90295104, 90295313
Arrowhead AND0169
JANNCO 40052001R
Denso 1002111660, 1002111661, 1002111662, 100211449, 1002114490, 9760218166
Hyster 3049491
Komatsu 6008212350, 6008214490
Lester 12180, 12197
PIC Picture ID 290209
Toyota 270607800171
Wilson 702912180, 90295171
J&N 40052001
JANNCO 40052001R
Denso 1002111660, 1002111661, 1002111662, 2107002, 9660218166, 9760218166
Hyster 3049491
Lester 12180
PIC Picture ID 290209
Toyota 2706078001, 270607800171
Arrowhead ND2107002
Denso 1002111662, 9760218166
Toyota 270607800171, 2706078001RF
Arrowhead AND0169
Denso 1002111660, 1002111662
Lester 12180
PIC Picture ID 290209
Wilson 90295171

100211-1610 100211-1611 100211-1630 100211-1632 100211-1640 100211-1650 100211-1670 100211-1680 100211-4440 100211-4450 100211-4490 100211-4520 100211-4528 100211-4560 100211-4640 100211-4650 100211-4660 100211-4670 100211-4680 100211-4690 100211-4740 101211-1040 101211-1180 101211-1181 101211-1230 101211-1320 101211-2480 102211-4640 110966 111048 115.506.040 12198N 12198R 146-93106 15881-64200 15881-64201 15881-64202 16231-24011 16231-64011 16231-64012 16241-64010 16241-64011 16241-64012 16705-64011 16705-64012 16791-64011 185046220 20140103 2040104 2335 27060-87201-000 27060-87202-000 27060-87501-000 27060-87502-000 27060-87801-000 28-2670 34070-75600 34070-75601 34070-75602 3A011-74012 40551RI 40551RID 436497 554432RI 554472RI 600-821-2350 66436-64011 695.509.040 70-29-12198 89213359 90-29-5492 93027 A-8855 AEB0551 ALT30423 CAL40104 CAL40104AS CAL40104ES CAL40104GS CAL40104OS CAL40104RS EAA-221653 EAA-221983 JA551IR LRA01560 UD12245A

Specifications

Amp	40 A
Bottom Mounting Foot Width (B)	24 mm
Diameter (D.1)	M8x1.25 mm
Diameter (D.2)	10.5 mm
Length (L.1)	160 mm
OEM Product	No
Plug Code	PL_2500
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	1 qty
Pulley Groove Width (W.1)	10 mm
Pulley Outside Diameter (O.D.1)	38 mm
Pulley Outside Diameter (O.D.2)	63 mm
Pulley to Mount Distance (A)	42 mm
Pulley Type	SOLID
Unit Type	DENSO
Voltage	12 V

Vehicle Applications

Make	Model	Type	Year
AEBI	TC07	[D782]	01.2005-12.2008
CASE	CK15		01.1995-12.1999
DAIHATSU	Cuore 0.8	[ED10]	09.1985-06.1990
DAIHATSU	Cuore 0.8	[ED10]	11.1989-12.1990
DAIHATSU	Cuore 0.8 4WD	[ED10]	09.1986-10.1988
DAIHATSU	Cuore 0.85	[ED20]	01.1995-11.1996
DAIHATSU	Hijet 0.8	[CD]	06.1986-12.1989
DAIHATSU	Hijet 1.0	[CB]	06.1986-12.1989
DAIHATSU	Hijet 1.0	[CB41]	12.1992-05.1998
GRASSHOPPER	930D	[D1305]	01.2010-
HUSQVARNA	P520D	[D922]	01.2010-
ISEKI	530
KUBOTA	B2530	[D1105]	01.2008-
KUBOTA	Engine	[D722]
KUBOTA	F1900	[D722]	01.2008-
KUBOTA	F2880	[D1305]	01.2008-
KUBOTA	KX41-3V	[D902]	01.2004-
MOFFETT	M4	[D1105-T]
NORCAR	744	[D722]	01.2005-
NORCAR	755	[D722]	01.2007-
PIAGGIO	Porter 1.0	[CB41]	05.1995-05.1998
RANSOMES	HR330T	[D1105-T]	01.2008-
SCHAFFER	2020	[D722-E]	01.2010-
SCHAFFER	2021	[D722-E]	01.2008-
SCHAFFER	217	[D722-E]	01.2005-
SCHAFFER	326	[D1105-E]
SCHAFFER	338	[V1505-E]
STALDCAT	Avant 314S		01.2000-
TEREX	HD850	[D905]	01.2004-12.2011
TORO	Groundmaster 3500.D	[D1105-T]	01.2008-
TORO	Groundmaster 7210	[D1105-T]	01.2008-
TORO	Reelmaster 5610	[V1505-T]	01.2008-

Reference Information

RNL551JA 16705-64011 16705-64012 CAL40104 100211-4528 554432RI A12DE0091A2 ALT30009 AEB0551 27060-87202-000 100211-4640 100211-1650 100211-4520 101211-2480 02-631200 CAL40104ES 115.506.040.050 93027 27060-87502-000 16231-64010 LRA1560 113921 101211-1320 STX101078R 2.70609E+12 101211-1040 A12DE0317A2 02-600935 16231-64013 CGB-17271 A12DE0342 STX101078 16231-64011 16231-64012 40551RI UD12245A 100211-4490 447070 16495-64013 A6358 LRA01560 445600 100211-1670 100211-4660 28-2670 5540183 A12DE0342A2 40551RID 16241-64011 111048 16241-64010 ALTL013 02/600935 CAL40104RS 100211-1680 2335 2706096001 16241-64014 16241-64013 100211-4670 16241-64012 70-29-12198 16231-24011 T1060-15682 T1060-15680 T1060-15681 16791-64011 185046220 16791-64010 554472RI 100211-1611 100211-1610 17580-64012 16427-64012 EAA-221653 20140103 100211-4440 101211-1230 12198R CAL40104AS 100211-4680 RNL4520ND 90-29-5492 100211-4560 62812000040 89213359 27060-87501 2040104 102211-4640 12198N 146-93106 STX101315 66436-64011 5540777 A12DE0066A2 27060-87201-000 100211-4690 62812000050 27060-87501-000 100211-4450 CAL40104OS 100211-1632 ALT30423 27060-87801-000 110966 446861 CAL40104GS 34070-75602 34070-75601 A-8855 02/631200 15881-64201 ALT5930 100211-1630 15881-64200 34070-75600 100211-4740 15881-64202 JA551IR 101211-1290 2706087501 2706087210 27060-87201 600-821-2350 RNL4640ND EAA-221983 5540798 100211-1640 ALT6478 3A011-74012 16945-64012 101211-1181 16945-64011 101211-1180 210657 16945-64013 436497
