Information
LRS00102Associated Numbers
1019L 11140 20500100 25-0019 25071 25075 25105 25105A 25105B 25105X 25141 25147 25147A 25147D 25147E 25147H 25238 450.001.092 6025145 8212126 8EA726012-001 91-17-8811 AES1101 AES1102 CS18 CST25145 CST25145AS CST25145ES CST25145GS CST25145OS CST25145RS DRS1611 DRS1611N EAA-141149 LRS00102 LRS102 RAS32722 S4063 SS104 SS111 STR56012 UD13187S UNIT BOM 180-111 ASPLList ASPL AUTOELECTRO CASCO DELCO EAA141149 EAA EAI 250019 ELSTOCK HC PARTS 8EA726012001 HELLA LUCASList LUCAS POWERMAX PRESTOLITE PSH SANDO SOVEREIGN 180111 WAI / TRANSPO 91178811 WILSON WOODAUTO snl008 snl009 0986011611 Bosch ruil 1063SP Spidan 11011610 EuroTec 111102 Cargo 111103 16121 Lester 16121N 16121R 25016 Lucas 25022 25024 25041 25061 25062 25063 25065 25079 25083 25083H Elstock 25085 25087 25088 25089 25097 25112 25138 25196 25201 25239 25345 4017SP 433272 Valeo 433273 450001092 71AB11001BA Ford 8011611F Friesen 8055343F 9000331001 Wilson 913065 EDR 913068 A11610 ATL CS19 Remy DRS3065 DRS3068 F042S0H016 F042S0H017 HCS18 HCS19 lrs00343 M35J MTJ121 Femsa MTU121 OSM10113 Optimum S23651 Hitachi STM101 Rolling Components STRH016 Unipoint STRH017 16112 AIM SL-0011R Reman SR192X Service Europe 0-986-011-611 Delco Dixie Electric Ltd S-4012 S-4013 105E-11001 118E-11001-B 71AB-11001-BA 12-11.611 8011611 8055102 8055343 CARGO Parts Hella 8EA726021-001 IAT S16122 Industry 16122 Old 16115 16147 16150 LMD 33100006 33100047 25071C 25071D 25083A 25083C 25083D 25083G 25083I 25083X 25112A 25147C 25147G 25196A 25196F 25238E 25265 25512 60925039 (Europe) LRS00343 S3511 MPA NAPA 44-4480 S6052 PIC Quinton Hazell FRS10 Romaine 16122N 41-16122 Standard Starter Drive 418333 VS111 Short VS102 Voltux V1-16122 Whatcom 29004 Wood Auto Supplies 323-1267 LESTER ELECTRIC
M35J M35G Inertia
M35J M35G Inertia M418G
Specifications
| Kilowatt | 0.8 kW |
| Length (L.1) | 310 mm |
| Mount Hole Center - Center (O.1) | 114 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 44 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | LUCAS |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUSTIN | Allegro 1.3 | [12L] | 08.1975-03.1982 |
| AUSTIN | Allegro 1.5 | [14H] | 08.1975-03.1982 |
| AUSTIN | Metro 1.3 | [12H996AA] | 10.1980-12.1985 |
| AUSTIN | Metro 1.3 | [12HA83AA] | 10.1980-04.1990 |
| AUSTIN | Metro 1.3 | [12HC21AA] | 11.1985-04.1990 |
| AUSTIN | Metro 1.3 T | [12HA85AA] | 10.1983-04.1990 |
| AUSTIN | Mini 1000 1.0 | [99H] | 10.1967-09.1984 |
| BLMC | Allegro 1100 1.1 | 01.1973-12.1980 | |
| BLMC | Allegro 1300 1.3 | 01.1973-12.1980 | |
| BLMC | Allegro 1500 1.5 | 01.1973-12.1979 | |
| BLMC | Austin 1100 1.1 | 01.1970-12.1974 | |
| BLMC | Austin 1300 1.3 | 01.1970-12.1974 | |
| BLMC | Marina 1100 1.1 | 01.1964-12.1972 | |
| BLMC | Marina 1300 1.3 | 01.1971- | |
| BLMC | Mini 1000 1.0 | 01.1970-12.1980 | |
| BLMC | Mini 1275 1.3 | 01.1970-12.1980 | |
| BLMC | Mini 850 0.85 | 01.1964-12.1980 | |
| BLMC | Mini Metro 1.3 | [12HC21AA] | 01.1985-12.1986 |
| MG | Metro 1.3 T | 01.1983-12.1990 |
Reference Information
13H5799 11140 450.001.092.100 6025145 25147 CS18 SS111 GEU4410 25105 25-0019 AES1101 AES1102 25141 CST25145RS 25105A 25105B LRS102 BOM 450.001.092 CST25145AS UNIT 111102 S4063 ANM13831X CST25145ES 25238 SS104 CST25145 6376421 25105X 8EA726012-001 25075 DRS1611 GXE9404 91-17-8811 UD13187S GEU404 STRS727 71AB11001BA 25071 LRS0102 25147E 25147H 8212126 25147A 25147D S12LU0640A2 GEU102 20500100 71ABBA STR56012 GEU4404 CST25145GS RAS32722 1019L CST25145OS LRS00102 180-111 DRS1611N STX200614 ADU4417 2681631Video/Publications
