Associated Numbers
UD02774A ASPL
UD12090A ASPL
AEK3402 AUTOELECTRO
0121715071 BOSCH List
0121715171 BOSCH List
0125811027 BOSCH List
0986081890 BOSCH
4848 CEVAM
DRA0539 DELCO
286514 ELSTOCK
CA2188IR HC PARTS
LRA03402 LUCAS
305.570.180 PSH
440308 VALEO
FG18T051 VALEO List
FG18T119 VALEO List
0125811028 VW
03L903023B VW
03L903023BX VW
03L903023D VW
03L903023DX VW
03L903024F VW
03L903024FX VW
03L903024K VW
20330N WAI / TRANSPO
BOS0125811028 WOODAUTO
AEK3402 AUTOELECTRO
0121715071 BOSCH List
0121715171 BOSCH List
0125811027 BOSCH List
0125811028 BOSCH List
CAL15431 CASCO
4848 CEVAM
DRA0539 DELCO
EAA254214 EAA
286514 ELSTOCK
8EL012240061 HELLA
LRA03402 LUCAS
305.570.180 PSH
439718 VALEO
440308 VALEO
FG18T051 VALEO List
FG18T119 VALEO List
03L903023B VW
03L903023BX VW
03L903023D VW
03L903023DX VW
03L903024F VW
03L903024K VW
BOS0125811028 WOODAUTO
VALFG18T051 WOODAUTO
0121715071
0121715171
0125811027
0125811028
03L903023B
03L903023BX
03L903023D
03L903024F
115712
286514
305570180
439718
439837
440308
440562
608426
617864
9090743F
930539
DRA0539
FG18T051
FG18T119
FGN18T051
FGN18T119
LRA03402
vxa022 439718
Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 40 mm |
| Pulley Type | CLUTCH |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SEAT | Alhambra 2.0 TDi | [CFFA] | 01.2010- |
| SEAT | Alhambra 2.0 TDi | [CFFB] | 01.2010- |
| SEAT | Alhambra 2.0 TDi | [CFFE] | 01.2010- |
| SEAT | Alhambra 2.0 TDi | [CFGB] | 01.2010- |
| SEAT | Alhambra 2.0 TDi | [CFGC] | 01.2010- |
| SEAT | Alhambra 2.0 TDi | [CUVA] | 05.2011- |
| SEAT | Alhambra 2.0 TDi 4WD | [CFFA] | 01.2011- |
| SEAT | Alhambra 2.0 TDi 4WD | [CFFB] | 01.2011- |
| SEAT | Alhambra 2.0 TDi 4WD | [CFFE] | 01.2011- |
| SEAT | Alhambra 2.0 TDi 4WD | [CFGB] | 01.2011- |
| SEAT | Alhambra 2.0 TDi 4WD | [CFGC] | 01.2011- |
| SKODA | Superb 1.6 TDi | [CAYB] | 01.2010-12.2015 |
| SKODA | Superb 1.6 TDi | [CAYC] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi | [CFFB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi | [CFGB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi | [CLJA] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi 4x4 | [CFFB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi 4x4 | [CFGB] | 01.2010-12.2015 |
| SKODA | Superb 2.0 TDi 4x4 | [CLJA] | 01.2010-12.2015 |
| VW | Passat 1.6 TDi | [CAYC] | 01.2009-12.2010 |
| VW | Passat 1.6 TDi | [CAYC] | 01.2010- |
| VW | Passat 2.0 TDi | [CBAA] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi | [CBAB] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi | [CBAC] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi | [CBBB] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi | [CBDC] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi | [CFFA] | 01.2010- |
| VW | Passat 2.0 TDi | [CFFB] | 01.2010- |
| VW | Passat 2.0 TDi | [CFGB] | 01.2010- |
| VW | Passat 2.0 TDi | [CLLA] | 01.2010- |
| VW | Passat 2.0 TDi 4-Motion | [CBAB] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi 4-Motion | [CBBB] | 01.2008-12.2010 |
| VW | Passat 2.0 TDi 4-Motion | [CFFA] | 01.2010- |
| VW | Passat 2.0 TDi 4-Motion | [CFFB] | 01.2010- |
| VW | Passat 2.0 TDi 4-Motion | [CFGB] | 01.2010- |
| VW | Passat 2.0 TDi 4-Motion | [CLLA] | 01.2010- |
| VW | Passat Alltrack 2.0 TDi | [CFFB] | 01.2012-12.2014 |
| VW | Passat Alltrack 2.0 TDi | [CFGB] | 01.2012-12.2014 |
| VW | Passat Alltrack 2.0 TDi | [CFGC] | 01.2012-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFFB] | 01.2012-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFGB] | 01.2012-12.2014 |
| VW | Passat Alltrack 2.0 TDi 4-Motion | [CFGC] | 01.2012-12.2014 |
| VW | Passat CC 2.0 TDi | [CFFA] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFFB] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFGB] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CFGC] | 01.2011- |
| VW | Passat CC 2.0 TDi | [CLLA] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFFA] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFFB] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFGB] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CFGC] | 01.2011- |
| VW | Passat CC 2.0 TDi 4-Motion | [CLLA] | 01.2011- |
| VW | Sharan 2.0 TDi | [CFFA] | 01.2010- |
| VW | Sharan 2.0 TDi | [CFFB] | 01.2010- |
| VW | Sharan 2.0 TDi | [CFGB] | 01.2010- |
| VW | Sharan 2.0 TDi | [CFGC] | 01.2013- |
Reference Information
305.570.180.004 CAL15431GS 305.570.180.000 F032115712 115712 IR7473 UD02774A 4848 03L903024FX 03L903024F 03L903023DX AG1716 13245 03L903024K 0121715071 WG2281045 305.570.180.014 AC-CBA2188 305.570.180.010 ALT1967 A12VA0187AS 444721 20179134OE WG2277512 2015431.1 2617864A CA2188IR 28-6514CT ALB5071 AI-90226 32081890 03L903023BX 10443538 28-6514 12090445 WG2011143 WG2011144 4G0908 439718 440308 8EL011713-261 03L903024KX 20015431AV ALT2219CP 200384 03L903023B 03L903023D AVA431A 209191 89215548 LRA03402 209191A A0433 2113741802 3117539 3117538 305.570.180.280 SKGN-0321130 L51190 3117537 57423 20179134BN AVA431 113568 3117541 UD12090A 3117540 553958RI FG18T119 SEG0125811028 STX101706 20330N 2608426A A12BH0187 AU8073 WG2011495 ALTF533 AL03030 20015431OV 0121715171 553958RIS TT12682 63732188010 305.570.180.346 305.570.180.500 305.570.180.501 ALT14372 553958RIV 305.570.180.460 ALT1737 QRA3275 553958RIB BOS0125811028 WG2011229 442536 209573A PRAF533 CAL15431AS 2015431 1986A01048 209271 0986081890 FG18T051 LRA3402 1638095480 WOOALT14372 423ST75 0125811027 4847916 0125811028Video/Publications
