or four payments of $251.65
with
Learn More
Associated Numbers
059903015P 059903015PV 059903015PX 116212 2020217 210782 28-5647 305.411.190 553328RIH 89215731 AEK3035 ALH0904 ALH0904NW ALT32212 CAL20217 CAL20217AS CAL20217ES CAL20217GS CAL20217OS CAL20217RS DRA0703 HITLR1190-904 LR1190-904 LR1190-904B LR1190-904C LRA03035
UD13145A ASPL List
AEK3035 AUTOELECTRO
116212 CARGO
CAL20217 CASCO
DRA0703 DELCO
285647 ELSTOCK
210782 ERA
LR1190904 HITACHI List
LR1190904B HITACHI
LR1190904C HITACHI
ALH0904 KRAUF
ALH0904NW KRAUF
LRA03035 LUCAS
89215731 POWERMAX
305.411.190 PSH
059903015P VW
059903015PV VW
059903015PX VW
ALT32212 WOODAUTO
HITLR1190904 WOODAUTO
2506161, LR1190904, LR1190904C, LR1190927 KRAUF ALH0904NW Messmer 210782 Motorherz ALB0904RB, ALH0904RB VAG 059903015P, 059903015PV, 059903015PX
059903015P VW
285647 Elstock
305411190 PSH
9090559F Friesen
930703 EDR
DRA0703 Remy
LR1190904 Hitachi
LR1190904B Hitachi
LR1190904C Hitachi
LRA03035 Lucas
Specifications
| Amp | 190 A |
| Bottom Mounting Foot Width (B) | 14.5 mm |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 8.5 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 197 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60 mm |
| OEM Product | No |
| Plug Code | PL_2303 |
| Product Line | Premium Line |
| Product Type | Remanufactured |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | SOLID |
| Unit Type | HITACHI |
| Voltage | 12 V |
| Water Cooled | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A8 4.0 TDi Quattro | [ASE] | 01.2003-12.2005 |
| PORSCHE | Cayenne 3.0 TDi | [M05.9D] | 01.2009-12.2010 |
| VW | Phaeton 3.0 V6 TDi | [BMK] | 01.2004-12.2007 |
| VW | Phaeton 3.0 V6 TDi | [CARA] | 01.2007-12.2008 |
| VW | Phaeton 3.0 V6 TDi | [CARB] | 01.2007-12.2008 |
| VW | Phaeton 3.0 V6 TDi | [CEXA | 01.2008-12.2011 |
| VW | Touareg 3.0 V6 TDi | [CASA] | 01.2007-12.2010 |
| VW | Touareg 3.0 V6 TDi | [CASC] | 01.2007-12.2010 |
Reference Information
059903015P CGB-85647 DRA0703 STX110276 CAL20217 CAL20217RS LRA3035 AEK3035 059903023Q ALT222170 HITLR1190-904 LR1190-904 ALH0904NW 28-5647 059903015PV 116212 A12HT0831A2 059903015PX 210782 136161 ALTF107 553328RIH 89215731 95860312401 PRAF107 2506161 HAL1190904C 305.411.190 LR1190-904C ALT32212 LR1190-904B LRA03035 2020217 STX110276R CAL20217ES CAL20217GS CAL20217AS ALH0904 CAL20217OS ALTF107HIVideo/Publications
