Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 349.82 including GST
NZ$ 304.19 excluding GST
or four payments of $87.46
with
Learn More
each
S3089
2
Associated Numbers
0986023850 101416 101416V 12078 1810A111 192943 20479711OE 220.526.113 25-3399 3104 33226N 33226N-OE 33226R 438200 5802AT 5802AW 5802CA 6015117 8080281 8212584 88212584 9654561480 9654595680 AEY2226 CS1416 CST15117GS D8R28 DRS0187 EAA-121375 LRS02226 S3089 SS574 STR54143 ASPLList AUTOELECTRO BOSCH CASCO CEVAM DELCO EAA121375 EAA EAI 253399 ELSTOCK FRIESEN HC PARTS LUCAS MITSUBISHIList PEUGEOT POWERMAX PSH REAL SANDO SOVEREIGN VALEOList WAI / TRANSPO 33226NOE WOODAUTO Bosch ruil 11090126 EuroTec Mitsubishi Valeo 220526113 Elstock 458289 4868SP Spidan PSA 8080281F Friesen 910187 EDR A78520 ATL Remy HCS1416 Lucas N5215053 Nipparts OSM11624 Optimum STR00126sa Electrolog snv026 702516 vxs942Specifications
| Kilowatt | 2.5 kW |
| Length (L.1) | 239 mm |
| Mount Hole Center - Center (O.1) | 18 mm |
| Mount Hole Center - Center (O.2) | 120 mm |
| Mount Hole Center - Center (O.3) | 29 mm |
| Mount Hole Center - Center (O.4) | 82 mm |
| Mount Hole Center - Center (O.5) | 89 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| Mount Hole Diameter (C.3) | M10x1.5 mm |
| Mount Hole Diameter (C.4) | M10x1.5 mm |
| Mount Hole Diameter (C.5) | M10x1.5 mm |
| No./Mount holes | 5 qty |
| No./Mount holes with thread | 5 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | -5 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C4 2.0 HDi | [RHF(DW10BTED4)] | 07.2008- |
| CITROEN | C4 2.0 HDi Picasso | [RHJ(DW10BTED4)] | 02.2007- |
| CITROEN | C4 2.0 HDi Picasso | [RHR(DW10BTED4)] | 02.2007- |
| CITROEN | C4 2.0 HDi Picasso 165 | [RHH(DW10CTED4)] | 09.2010- |
| CITROEN | C5 2.0 HDi | [RHF(DW10BTED4)] | 02.2008- |
| CITROEN | C5 2.0 HDi | [RHR(DW10BTED4)] | 02.2008- |
| CITROEN | C5 2.0 HDi 150 | 04.2009- | |
| CITROEN | C5 2.0 HDi X7 | [DW10CTED4] | 04.2009- |
| CITROEN | C5 2.2 HDi | [4HL(DW12C)] | 07.2010- |
| CITROEN | C5 2.2 HDi | [4HT(DW12BTED4)] | 04.2006- |
| CITROEN | C5 2.2 HDi | 05.2006- | |
| CITROEN | C6 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
| CITROEN | C6 2.2 HDi | 06.2006- | |
| CITROEN | C8 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
| CITROEN | C-Crosser 2.2 HDi | [DW12MTED4] | 02.2007- |
| CITROEN | C-Crosser 2.2 HDi Enterprise | [4HN(DW12METED4)] | 01.2009- |
| CITROEN | DS4 2.0 HDi 135 | 09.2011- | |
| CITROEN | DS5 2.0 HDi | [RHH(DW10CTED4)] | 11.2011- |
| CITROEN | DS5 2.0 HDi 135 | 11.2011- | |
| FIAT | Ulysse 2.2 JTD | [4HP] | 03.2008- |
| FIAT | Ulysse 2.2 JTD | [4HR] | 03.2008- |
| FIAT | Ulysse 2.2 Multijet | [4HT] | 03.2008- |
| LANCIA | Phedra 2.2 Multijet | 03.2008- | |
| MITSUBISHI | Outlander 2.2 Di-D | [4HK] | 08.2007- |
| PEUGEOT | 3008 2.0 HDi | [RHE(DW10CTED4)] | 06.2009- |
| PEUGEOT | 3008 2.0 HDi | [RHH(DW10CTED4)] | 06.2009- |
| PEUGEOT | 308 2.0 Diesel CC | [RHR(DW10BTED4)] | 04.2009- |
| PEUGEOT | 308 2.0 HDi | [DW10BTED4] | 09.2007- |
| PEUGEOT | 308 2.0 HDi | [RHH(DW10CTED4)] | 04.2012- |
| PEUGEOT | 308 2.0 HDi | [RHR(DW10BTED4)] | 07.2010- |
| PEUGEOT | 308 2.0 HDi | [RHR(DW10BTED4)] | 09.2007- |
| PEUGEOT | 308 CC 2.0 HDi | [RHR(DW10BTED4)] | 04.2009- |
| PEUGEOT | 308 CC 2.0 HDi | 06.2009- | |
| PEUGEOT | 308 SW 2.0 HDi | [RHF(DW10BTED4)] | 09.2007- |
| PEUGEOT | 308 SW 2.0 HDi | [RHR(DW10BTED4)] | 09.2007- |
| PEUGEOT | 308 SW 2.0 HDi | 06.2009- | |
| PEUGEOT | 4007 2.2 HDi | [DW12MTED4] | 02.2007- |
| PEUGEOT | 407 2.0 HDi | [RHE(DW10CTED4)] | 02.2010- |
| PEUGEOT | 407 2.0 HDi | [RHH(DW10CTED4)] | 06.2009- |
| PEUGEOT | 407 2.0 HDi | [RHH(DW10CTED4)] | 07.2009- |
| PEUGEOT | 407 2.0 HDi | [RHR(DW10BTED4)] | 08.2008- |
| PEUGEOT | 407 2.0 HDi FAP | [RHR(DW10BTED4)] | 05.2004- |
| PEUGEOT | 407 2.2 HDi | 06.2008- | |
| PEUGEOT | 407 2.2 HDi FAP | [4HT(DW12BTED4)] | 05.2006- |
| PEUGEOT | 407 SW 2.0 HDi | [RHE(DW10CTED4)] | 02.2010- |
| PEUGEOT | 407 SW 2.0 HDi | [RHH(DW10CTED4)] | 07.2009- |
| PEUGEOT | 407 SW 2.2 HDi | 06.2008- | |
| PEUGEOT | 5008 2.0 HDi | [RHE(DW10CTED4)] | 06.2009- |
| PEUGEOT | 5008 2.0 HDi | [RHH(DW10CTED4)] | 09.2009- |
| PEUGEOT | 508 2.0 HDi AWC | [RHH(DW10CTED4)] | 11.2010- |
| PEUGEOT | 508 2.2 HDi | [DW12C] | 11.2010- |
| PEUGEOT | 508 SW 2.2 HDi | [DW12C] | 11.2010- |
| PEUGEOT | 607 2.2 HDi FAP | [4HT(DW12BTED4)] | 05.2006- |
| PEUGEOT | 807 2.2 HDi | [4HT(DW12BTED4)] | 06.2006- |
Reference Information
CS1416 88212584 AEY2226 5015124 1638126880 EAA-121375 332268 8212584 33226R 33226N 12078 5802CA 9654595680 CST15117GS 33226N-OE 95527511 25-3399 LRS02226 220.526.113.500 2279 6015117 3553141 SU001-A2690 5802AT 5802AV 5802AW 8080281 S12VA0114A2 SS574 101416V 220533 9654561480 20479711OE STX201054 S3089 CGB-23077 RNLD8R28 0986023850 438200 1810A111 LRS2226 SX 5802-AV ANM12407X S12VA0114 220.526.113.000 STR00126 3104 192943 STRL875 DRS0187 220.526.113.008 D8R28 STR54143 101416Video/Publications
