Information
0120465031Associated Numbers
AEA3253 AUTOELECTRO
12311738351 BMW
12311744563 BMW
12311744567 BMW
0120465031 BOSCH List
0986039000 BOSCH
112700 CARGO
CAL10163RS CASCO
4470 CEVAM
DRA9000 DELCO
EAA221541 EAA
56723 EAI
283522 ELSTOCK
9039000 FRIESEN
CA1092IR HC PARTS
8EL737041001 HELLA
32039000 HERTH+BUSS
11.1092 LAUBER
11.1094 LAUBER
LRB00353 LUCAS
89213883 POWERMAX
SA086 SOVEREIGN
437330 VALEO
13471N WAI / TRANSPO
ALT10230 WOODAUTO
0120465031
0986039000
12311738351
12311738514
12311738515
12311744563
12311744567
13471
13471N
215022140
220255
2541481
2541499
282871
283522
436332
437330
439586
5027SP
5063SP
90156254
90203554
9039000F
938310
A14V19
CA1054IR
CA1092IR
DRA9000
HCA1054IR
HCA1092IR
LRA01658
LRB00353
J&N 40024198
Arrowhead ABO0259, ABO0259
Remy Light Duty 14485
Wilson 90156254, 90156254
BMW 12311738351, 12311738352, 12311744563
Bosch 0120465031, 120465031, AL0737X
Lester 13471
Lucas A6793
PIC Picture ID 220255
Valeo VA409 ANB5048
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 28 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10.5 mm |
| Length (L.1) | 236 mm |
| Mount Inside Length or Pad Mount C-C (C) | 77 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 69 mm |
| Pulley Type | SOLID |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 320 2.0 i | (E36)[M50B20] | 09.1991-12.1995 |
| BMW | 320 2.0 i | (E36)[M52B20] | 09.1994-12.1999 |
| BMW | 320 2.0 i | (E36)[M52B206S3] | 01.1995-10.1999 |
| BMW | 323 2.5 i | (E36)[M52B25] | 03.1995-10.1999 |
| BMW | 323 2.5 Ti | (E36)[M52B25] | 08.1997-08.2000 |
| BMW | 325 2.5 i | (E36)[M50B25] | 09.1991-04.1999 |
| BMW | 325 2.5 i | (E36)[M52B25] | 09.1991-09.1995 |
| BMW | 328 2.8 i | (E36)[M52B28] | 03.1995-12.1999 |
| BMW | 520 2.0 i | (E34)[M50B20] | 11.1991-12.1996 |
| BMW | 520 2.0 i 24V | (E34)[M50B20] | 09.1991-09.1995 |
| BMW | 525 2.5 i | (E34)[M50B25] | 11.1991-01.1997 |
| BMW | 525 2.5 i 24V | (E34)[M50B25] | 09.1991-09.1995 |
| BMW | 525 2.5 i 24V | (E34)[M52B25] | 09.1991-09.1995 |
| BMW | 525 2.5 iX 24V 4x4 | (E34)[M52B25] | 10.1992-09.1995 |
| BMW | 525 2.5 iX 4x4 | (E34)[M50B25] | 02.1992-01.1997 |
| BMW | 525 2.5 iX 4x4 | (E34)[M52B25] | 02.1992-12.1996 |
Reference Information
89213883 ALT10230 12311735693 AEA3253 12311735694 12311738088 A0156 DRA9000 12311744567 ANM31220X 12311735691 12311730081 SA086 12311738091 STX100536 12311726378 12311744563 ALT121630 2010163 310637 20101361RC 437330 8EL737041-001 12311738514 12311735124 12311738515 13471N 12311735123 0120465031 12311738352 A12BH0763A2 12311738351 ALT121630R 301092RI STX101352 CA1092IR 12311730261 12311735235 4470 112700 12311735396 12311735395 11.1094 9039000 0986039000 LRB353 12311735397 11.1092 28-3522 3471N 32039000 LRB00353 PRAW289 ALTW289 441239 ALT1748 56723 CAL10163RS 12311726047 1738514 12311726081Video/Publications
